Kenmore 79094144310 electric range Parts

On Kenmore electric range model 79094144310, the model and serial number label (serial plate) is typically on the lower right front frame of the range. On some units, the label can also be under the cooktop. Confirm the exact spot using the 79094144310 installation guide.

• Open the oven door and look along the front frame area, especially lower right.
• Check the front frame near the storage drawer opening (if your range has a drawer).
• Look under the cooktop if you do not see a label on the front frame.
• Wipe the area with a damp cloth; grease and baked-on residue can hide the print.

Even within the same Kenmore range family, labels are usually placed in one of these spots:

We use the exact model number to match the correct parts and diagrams for your range, especially for electrical and heating components like the range bake element 316075103 and the oven temperature sensor.

Last updated: January 2026

Kenmore model 79094144310 is made by Frigidaire. On Kenmore appliances, the first three digits of the model number (the prefix) identify the manufacturer; a 790 prefix indicates Frigidaire for this electric range family. See the 79094144310 use & care guide for the exact model series format.

We recommend verifying the full model number exactly as printed on the range’s identification label, then matching the prefix.

• Find the model/serial tag (commonly on the oven frame behind the storage drawer, or around the door opening).
• Confirm the prefix is 790 (as in 79094144310).
• Match the prefix to the manufacturer family (790 = Frigidaire-built Kenmore ranges).
• Use the full model number when ordering parts like a bake element, oven sensor, or control switch.

Because this Kenmore range is Frigidaire-built, many replacement parts and designs align with Frigidaire-manufactured components used across the 790-series.

If your display shows an error code while baking, broiling, or during self-clean, use Kenmore 790 self-cleaning range error codes to narrow down the likely circuit or component.

The manufacturer family affects parts compatibility (elements, sensors, switches, overlays) and troubleshooting steps. Using the correct manufacturer family prevents wrong-part returns and speeds up repair.

Last updated: January 2026

The Kenmore 79094144310 is a standard freestanding electric range in the 790.9414* series; most ranges in this class are built for a 30-inch-wide opening and use a single oven cavity. For the exact oven capacity and exterior dimensions for your unit, use the specs section in the 79094144310 use & care guide.

When customers ask for oven size, it usually refers to one of these:

• Exterior width (fits a 30-inch range space in most kitchens)
• Overall height (often adjustable with leveling legs)
• Overall depth (varies with handle and rear clearance)
• Oven capacity (measured in cubic feet)
• Interior rack dimensions (usable cooking space)

These are common ranges for this product type; confirm your exact measurements in the manual and by measuring your appliance.

Use a tape measure and record to the nearest 1/8 inch.

• Measure width at the widest point (often the cooktop edge)
• Measure height from floor to the top of the backguard/control panel
• Measure depth from the back of the range to the front of the door/handle
• If you are replacing the unit, also measure the cutout/opening and note outlet location

Correct dimensions help you avoid fit issues with cabinets, countertops, and anti-tip bracket placement. If you are troubleshooting uneven baking or temperature swings, “size” is less important than verifying temperature accuracy; the range oven temperature sensor 316490000 is one of the key parts involved in temperature regulation on many Kenmore electric ranges.

Last updated: January 2026

To reset your Kenmore electric range model 79094144310, turn the range off and cycle power at the home circuit breaker for about 1 minute, then restore power and reset the clock and any oven settings. This clears many control glitches after a power interruption.

• Turn all surface element knobs to OFF.
• If the oven is running, press Cancel/Off.
• Switch the range circuit breaker OFF (or remove the fuse).
• Wait 60 seconds.
• Switch the breaker ON.
• Set the clock and reselect any cooking mode (per the 79094144310 use and care guide).

A reset helps when the electronic control is confused by a power failure or a brief voltage drop. If the issue returns right away, focus on the symptom:

• Oven will not heat: check for a failed bake element or temperature sensing issue.
• Temperature is inaccurate: the oven temperature sensor can drift or fail.
• Display works but functions do not: a wiring or control issue is more likely.

After a power failure, this range can resume operation when power returns, and the clock and oven function need to be reset. A proper power-cycle reset is the fastest safe way to restore normal operation before replacing parts.
