Frigidaire FFGH3054USC free standing gas range Parts

Most Frigidaire gas ranges, including the Frigidaire FFGH3054USC free standing gas range, last 13 to 15 years with normal household use. Consistent cleaning, correct burner flame, and fixing small issues early often pushes real-world life closer to 15 to 20 years.

What affects lifespan the most

• Cooking frequency and heat load (daily high-heat use shortens life)
• Spillovers and grease buildup around burners and inside the oven
• Ignition health (slow ignition strains igniters and gas valve operation)
• Ventilation and cooling (overheating can stress controls and wiring)
• Quality of repairs and correct parts for the exact model

Maintenance that extends the life of FFGH3054USC

We recommend following the cleaning and care schedule in the FFGH3054USC owner’s manual. Key habits that make the biggest difference:

• Keep burner ports clear and dry after cleaning
• Wipe up boilovers quickly to prevent corrosion and clogged ports
• Avoid lining the oven bottom with foil (it can trap heat and affect airflow)
• Use the self-clean feature only as directed; excessive use adds heat stress
• Check that the oven preheats normally and holds temperature

“Replace a part” vs “replace the range” quick guide

Symptom	Common fix	Replace range when…
Oven won’t heat or heats slowly	Replace the bake igniter 316489403	Multiple major systems are failing at once
Oven temperature is inaccurate	Replace the range oven temperature sensor 316490000	Repairs approach a large share of the cost of a new range
Oven light out	Replace the appliance light bulb, 40-watt 316538904	Cabinet, frame, or gas system damage is present

Why it matters

A gas range’s “end of life” is usually about reliability and performance, not just age. When ignition, temperature control, and safety-related heating behavior stay stable, keeping a well-maintained range is typically the most cost-effective choice.

Last updated: February 2026

Yes. Looking up parts by model number is the most accurate way to get compatible replacement parts for your Frigidaire free standing gas range model FFGH3054USC because it filters results to the exact burner, igniter, sensor, and hardware used on your range. Use the model and serial plate information to match parts correctly.

Where to find the model number on FFGH3054USC

Frigidaire places the serial plate on the right-hand surface of the oven front frame near the storage or warmer drawer area; an alternate location may be under the cooktop. The plate lists the model number, serial number, and other identifying details.

• Open the storage or warmer drawer and look at the lower right front frame
• Check the right-hand oven front frame surface near the drawer opening
• If not visible, check under the cooktop area
• Write down the model number, serial number, and any lot number/letter

For diagrams and the exact serial plate location notes, use the FFGH3054USC owner’s manual.

How to use the model number to get the right part

When you search by model number, we can narrow parts to the correct assemblies for your range, such as the oven igniter, temperature sensor, or gas valve.

• Enter FFGH3054USC exactly as shown on the serial plate
• Match the part by part name and part ID (not just a photo)
• Compare symptoms to the part’s function (heat, ignition, temperature control)
• Confirm whether you are repairing the oven (bake/broil) or a surface burner issue

Common examples for this model

Symptom	Part type to check	Example part for FFGH3054USC
Oven will not heat (bake)	Bake igniter	Bake igniter 316489403
Oven temperature seems off	Oven temperature sensor	Range oven temperature sensor 316490000
No gas flow to oven burner	Oven gas valve	Frigidaire range oven gas valve 316031501

Why it matters

Gas range parts are highly model-specific. Using the exact model number helps prevent ordering a similar-looking igniter, sensor, or regulator that mounts differently or has different electrical ratings.

Last updated: February 2026

If your Frigidaire FFGH3054USC gas range smells like gas, treat it as a safety issue first: stop using the range and follow the “what to do if you smell gas” steps in the installation guide. After the area is safe, common causes include a burner that is not igniting cleanly, clogged burner ports, or a gas component that is leaking.

Safety first (do this immediately)

If you smell gas when the range is off, or the odor is strong, we recommend these actions right away:

• Do not try to light any burner or the oven.
• Do not touch electrical switches or use a phone inside the home.
• Call your gas supplier from a neighbor’s phone and follow their instructions.
• If you cannot reach your gas supplier, call the fire department.
• Do not resume use until the source is corrected.

Common causes when the smell happens during use

A brief odor at ignition can happen, but a persistent smell points to a problem such as:

• Dirty or clogged burner ports causing delayed ignition and incomplete combustion
• Weak oven ignition (gas flows but the igniter does not light the burner quickly)
• Misaligned burner cap/head on the cooktop
• Loose fitting or failing gas component (regulator, valve, manifold connection)

Quick symptom guide

When you smell gas	Most likely issue	What to check first
Only when baking	Weak/slow oven ignition	Bake igniter 316489403 and burner area
Only when broiling	Broil ignition issue	Broil igniter and burner area
At a surface burner	Delayed ignition	Burner cap alignment, clogged ports
Even when everything is off	Possible leak	Shut off gas supply and follow safety steps

What to inspect after the area is safe

Use the FFGH3054USC owner’s manual to locate components and review operating tips, then check:

• Burner caps and heads: seated flat and centered
• Burner ports: clear of spills, grease, and debris
• Ignition: burner should light promptly (no long clicking with gas odor)
• Oven performance: slow preheat or no ignition often pairs with a weak igniter

Why it matters

Unburned gas can collect if ignition is delayed or a component leaks. Fixing the root cause improves safety, prevents poor baking performance, and helps protect the oven control and gas valve from repeated failed ignition attempts.

Last updated: February 2026

Most gas stoves (gas ranges) typically cost about $400 to $2,400 for the appliance, depending on size, burner power, and features. For a 30-inch freestanding range like the Frigidaire FFGH3054USC, the final price also depends on installation needs and any required gas or electrical updates; see the FFGH3054USC installation guide for typical placement and clearance requirements.

Typical price ranges (appliance only)

• Entry level: $400 to $900
• Mid-range: $900 to $2,400
• Pro-style / premium: $3,000 to $15,000+
• Extra costs: delivery, haul-away, anti-tip hardware, and installation labor
• Higher price drivers: convection, air fry modes, heavier grates, higher-BTU burners, upgraded finishes

Installation and setup costs to plan for

Even when the range itself is affordable, installation can change the total cost quickly.

• Gas shutoff and connector work (if needed)
• Electrical outlet compatibility and grounding
• Cabinet and clearance compliance (especially above the cooktop)
• Leveling and anti-tip bracket installation
• LP conversion (only if your home uses propane)

Common cost scenarios (what changes the total)

Scenario	What’s usually needed	Cost impact
Replace an existing gas range	Basic hookup and leveling	Lower
New gas range where none existed	New gas line or shutoff work	Higher
Converting to propane	LP conversion parts and setup	Medium to higher

Why it matters

A gas range purchase is really two decisions: the appliance features you want (burner sizes, oven options, controls) and the installation requirements in your kitchen. Clearances and a stable, level install help cooking performance and help prevent heat damage to nearby cabinets.

Related parts that can affect repair vs replace decisions

If your current range is acting up, a repair can sometimes be more cost-effective than replacement. Common service parts for the FFGH3054USC include:

• Bake igniter 316489403 (ignition problems in bake)
• Range oven temperature sensor 316490000 (temperature accuracy issues)
• Frigidaire range oven control board 5304514107 (control or display problems)

Last updated: February 2026

On the Frigidaire FFGH3054USC gas range, clear most F or E error codes by pressing OFF on the control panel. If the code returns, reset power to the range for 5 minutes, restore power, then set the clock; this clears many temporary control faults.

Step-by-step: clear and reset the code

• Press OFF to clear the displayed F or E code.
• Try Bake or Broil again.
• If the code repeats: turn power off at the breaker (or unplug) for 5 minutes.
• Restore power; the display may flash 12:00.
• Set the clock using the steps in the FFGH3054USC owner's manual.
• If the code comes back again, clear it with OFF and move to the checks below.

What to check if the code keeps coming back

Repeated error codes usually point to a control input or temperature feedback problem. These checks cover the most common causes on gas ranges:

• Oven temperature sensor circuit: loose connector, damaged wiring, or a failed sensor (common when temps are erratic). Consider the range oven temperature sensor 316490000.
• Keypad or control issue: stuck key, moisture, or a failing electronic control.
• Ignition problems that prevent heating: weak igniter can cause no-heat symptoms that may accompany faults. For bake ignition, see the bake igniter 316489403.
• Overheating protection: if the range overheats, a limit device can open and trigger faults. Check the Frigidaire range high-limit thermostat 318578506.

Quick reference: what each action does

Action	What it fixes	What you should see next
Press OFF	Clears the active fault display	Code disappears temporarily or fully
Power reset for 5 minutes	Resets the oven control after a detected fault	Clock flashes 12:00, then normal after setting
Set the clock	Required for normal oven operation on this model	Oven functions respond normally

Why it matters

Clearing the code with OFF confirms whether the fault was a one-time glitch. If the code repeats after a 5-minute power reset and clock set, the range is detecting a real problem (sensor, wiring, igniter, or control) that needs diagnosis before reliable baking and broiling.

Last updated: February 2026
