LG LRSXC2306V/00 refrigerator Parts

For an LG refrigerator like model LRSXC2306V, the model number is printed on the appliance ID label inside the fresh food compartment; once you find it, read it left to right exactly as shown because each character identifies the series, features, and revision.

Most LG side-by-side refrigerators place the ID label in one of these spots:

• Inside the refrigerator compartment on a side wall (often upper left)
• Along the ceiling of the fresh food section near the front
• On the door jamb area (hinge side) when the door is open
• Less commonly, behind the toe grille or on the rear exterior label

LG model numbers are a code. While the exact breakdown varies by product line, you can use this structure to interpret what you see:

• Prefix letters: product family and configuration (refrigerator type)
• Middle characters/numbers: capacity class, design series, and feature package
• Suffix after a slash or dash (if present): revision, color, or production variation

When you look up parts for LG refrigerators, small differences in the model tag matter.

• Copy the model number exactly (including any /00 or -00 version)
• Use the model number on the label, not the number from a sales receipt
• If you are replacing a water filter, match the filter type to the model
• If you are troubleshooting water or ice issues, confirm the exact valve and tubing style

If you are shopping for a filter for this model, start with the LG lt1000p refrigerator water filter ADQ74793501.

LG often releases multiple revisions of a refrigerator that look identical but use different bins, valves, ice maker components, or control boards. Using the full model number (and version) is the fastest way to get the correct LG replacement part the first time.

Last updated: February 2026

LG refrigerators like model LRSXC2306V typically last 10 to 15 years. With steady temperatures, clean airflow, and timely fixes to cooling or water system issues, many units reach the high end of that range (or longer) before major sealed-system repairs become likely.

• Condenser airflow and heat removal: dust buildup and blocked vents make the compressor work harder.
• Door seal condition: air leaks cause longer run times and moisture problems.
• Ice maker and dispenser use: heavy use increases wear on motors, valves, and fittings.
• Water quality and filter changes: reduces clogs and improves dispenser performance.
• Room conditions: hot garages, tight cabinetry clearances, and frequent door openings shorten life.

• Vacuum and brush the condenser area regularly; keep the rear and bottom vents clear.
• Keep freezer and fresh food temps stable (avoid overstuffing vents and returns).
• Replace the water filter on schedule; use the correct filter for this model, such as LG lt1000p refrigerator water filter ADQ74793501.
• Inspect and clean the door gasket; replace it if it is torn, warped, or no longer sealing evenly.
• Address unusual noises quickly (fan rubbing, clicking, buzzing) to prevent secondary damage.

A refrigerator that runs hot or leaks air uses more energy and puts extra load on the compressor and fans. Simple upkeep and quick part replacement often adds years of reliable cooling.

For filter and dispenser upkeep steps, we recommend how to replace the water filter in an LG refrigerator.

Last updated: February 2026

For the LG LRSXC2306V refrigerator, the most common service issue we see is a cooling problem: the fresh food section or freezer runs warm, temperatures swing, or the unit stops cooling. The next most common complaints are ice maker and water dispenser problems caused by restricted water flow or a failing valve.

• Refrigerator section warm but freezer still cold (or the reverse)
• Food spoiling faster than normal, soft ice cream, or melting ice
• Clicking, buzzing, or the unit running constantly
• Little or no ice production, small cubes, or clumping
• Water dispenser flow slow or stops after a filter change

1. Confirm temperatures: set refrigerator to 37°F and freezer to 0°F; allow 24 hours to stabilize.
2. Check airflow: do not block vents with packages; overpacking causes warm spots.
3. Clean the condenser area: dust buildup reduces heat removal and can mimic a cooling failure.
4. Listen for the condenser fan: if the compressor runs but you do not hear airflow at the back/bottom, the fan motor may be the issue.
5. For ice and water issues: replace the filter on schedule and purge air after installation.

• If the unit is warm and you suspect poor airflow at the condenser, check the LG refrigerator condenser fan motor EAU65058502.
• If ice production is inconsistent or the auger is not moving ice, the LG refrigerator ice maker and auger motor assembly ACZ74390702 is a common repair path.
• If water taste, flow, or ice quality is the issue, use the correct filter for this model, such as the LG lt1000p refrigerator water filter ADQ74793501.

Cooling and water/ice problems can cascade: restricted airflow or water flow forces longer run times, creates temperature swings, and can lead to frost buildup or repeated ice maker jams. Catching the root cause early protects food quality and reduces wear on major components.

Last updated: February 2026

A 23 cu. ft. refrigerator is typically a full-size unit that measures about 35 to 36 inches wide, 68 to 71 inches tall, and 28 to 34 inches deep depending on whether it is counter-depth, includes door handles, and the door style. For LG model LRSXC2306V, use these ranges to plan space and clearances.

Most 23 cu. ft. refrigerators fall into these common exterior size bands:

• Width: 35 to 36 inches (most common for side-by-side and French door)
• Height: 68 to 71 inches (to the top of the hinge cover on many models)
• Depth: 28 to 34 inches (varies most; handles and door clearance change this)
• Door swing clearance: plan extra space so doors open fully for bins and drawers

To avoid fit issues, measure the opening and the path into the kitchen before ordering a refrigerator or replacement door parts.

• Measure width, height, and depth of the cutout
• Check depth to the front of surrounding cabinets (counter-depth planning)
• Allow airflow space behind and above the refrigerator
• Confirm door swing will clear walls and islands
• Measure doorways and hallways for delivery clearance

A “23 cu. ft.” capacity tells you interior storage volume, not the outside footprint. Depth and door swing are the usual surprises, especially on side-by-side refrigerators where you need enough clearance to fully open the doors and access door bins.

If you are troubleshooting fit, sealing, or door storage on LG LRSXC2306V, these parts commonly relate to space and usability:

• Refrigerator door gasket 4987JJ1010Z (helps prevent warm air leaks that can cause sweating and icing)
• Refrigerator door bin, lower - refrigeration storage part by LG MAN64890501 (door storage clearance and organization)
