Where is the model number on my Kenmore electric stove?
On Kenmore electric range model 79096569602, the model and serial number are printed on a serial plate located on the right side of the oven front frame, inside the storage or warmer drawer compartment. Pull the bottom drawer out to see the identification plate.
- Turn the range off and let it cool completely.
- Pull the storage drawer or warmer drawer straight out.
- Look at the right side of the oven front frame (inside the drawer opening).
- Find the serial plate with the model and serial number.
- Write the numbers down for parts lookup and service records.
The serial plate typically includes:
- Model number (for example, 790.9656* where * indicates the color code)
- Serial number
- Electrical ratings and other identification details
If you cannot access the drawer compartment, check these common spots used on many ranges:
- Oven door frame area (around the front frame)
- Back panel near the vent area
- Side panel near the lower rear
Using the exact model number helps us match the correct Kenmore parts and diagrams for your range, especially for model families that share similar styling but use different bake elements, control boards, or sensors.
| What you need | Where you use it | Example use |
|---|---|---|
| Model number | Parts lookup and diagrams | Ordering the correct oven component |
| Serial number | Production details | Confirming version differences |
For the official location diagram and product record section, see the owner's manual.
Last updated: February 2026
What is the F1 code on a Kenmore oven?
On Kenmore electric range model 79096569602, an F1 error means the electronic oven control is detecting a fault condition. First press CLEAR/OFF to stop the beeping and clear the display; then reprogram the oven. If the code returns, the problem is typically in the control circuit, sensor circuit, or related wiring (see the owner's manual).
- Press CLEAR/OFF to stop the alarm and clear the code.
- Set the oven to BAKE and start a short test cycle.
- If F1 returns, write down when it happens (at idle, during preheat, after reaching temp).
- Turn off power at the breaker for 1 minute, then restore power and retest.
- If the oven is overheating or acting erratically, stop using it until the issue is corrected.
| Likely cause | What you may notice | Part that often relates |
|---|---|---|
| Control fault (EOC/clock) | Random beeping, F1 at idle | Control assembly (varies by build) |
| Temperature sensor circuit issue | Temperature swings, long preheat, F1 during bake | Frigidaire range oven temperature sensor 316490000 |
| Wiring/connection problem | Intermittent errors, bumps trigger beeps | Harness/connectors (inspect) |
- Sensor check: If the oven temperature seems inaccurate or the code appears during heating, the sensor circuit is a prime suspect.
- Connection check: With power off, inspect the sensor connector and any visible wiring for heat damage or loose terminals.
- Pattern check: If F1 appears with no cooking selected, the electronic control is often the trigger.
An F1 code is the range telling you it cannot reliably control oven temperature or operation. Clearing it may get you cooking again briefly, but repeated F1 errors usually point to a component or wiring issue that needs correction to restore safe, consistent baking.
Last updated: February 2026
How do I reset my Kenmore electric range?
To reset your Kenmore electric range model 79096569602, turn the range off and cycle power at the breaker (or unplug it) for a few minutes, then restore power and reset the clock. After a power interruption, the range can resume operation when power returns, so always turn controls off first; see the owner's manual.
- Turn all surface burner knobs to OFF.
- Cancel any oven function (Bake, Broil, Timer) if the control responds.
- Switch the range circuit breaker OFF (or unplug the power cord).
- Wait 3 to 5 minutes.
- Switch the breaker ON (or plug the range back in).
- Set the clock and reselect your cooking mode.
A power reset clears many temporary control glitches, such as an unresponsive keypad, a stuck cooking mode, or odd display behavior. It does not fix a failed heating circuit, damaged wiring, or a bad sensor.
| Symptom after reset | Most likely area to check | Common next step |
|---|---|---|
| Display returns to normal | Control recovered | Reset clock and test Bake/Broil |
| Oven heats incorrectly | Temperature sensing | Test/replace frigidaire range oven temperature sensor 316490000 |
| No oven light | Bulb or socket | Replace range oven light bulb 316538904 |
| Still dead/no power | Supply connection | Inspect terminal block and cord connections per the installation guide |
Resetting the range the right way prevents the appliance from unexpectedly turning back on when power is restored, and it helps you confirm whether the issue is a temporary control problem or a part failure.
Last updated: February 2026
What kind of Kenmore range do I have?
If your range’s model tag shows 79096569602, you have a Kenmore electric range model 79096569602. On this model, the identification plate is located on the right side of the oven front frame, inside the storage or warmer drawer compartment (depending on which drawer your range has). See the owner's manual for the exact tag location diagram and wording.
- Turn the range off and let it cool.
- Pull out the storage drawer or warmer drawer.
- Look at the right side of the oven front frame for the identification plate.
- Confirm the full model number is 79096569602 (write down the full number).
- Record the serial number too; it helps match the correct parts list.
The model number is the key to ordering the right Kenmore range parts and using the correct instructions.
| What you’re checking | Where to look | Why it matters |
|---|---|---|
| Model number | ID plate on right side of oven front frame (drawer area) | Ensures correct parts fit and diagrams match |
| Serial number | Same ID plate | Helps identify production version for some parts |
| Drawer type | Storage drawer or warmer drawer | Affects access to the ID plate and some replacement parts |
Kenmore ranges often look similar across series, but parts like a bake element, broil element, control switch, or oven temperature sensor can vary by model. Using 79096569602 prevents ordering the wrong component and speeds up troubleshooting.
Last updated: February 2026
What causes a Kenmore oven to stop working?
If your Kenmore electric range model 79096569602 stops working, the most common causes are a power interruption (the oven will not restart automatically), a failed heating component (bake or broil), or a control or sensor problem that prevents the oven from heating or responding to commands. See the owner's manual for model-specific checks.
- Confirm the range has power; if there was an outage, turn the oven off, then reset the clock and reselect a cooking mode.
- Check the house breaker; an electric range can lose one leg of power and act “dead” or heat poorly.
- Make sure the control is not in a special mode (for example, Sabbath feature behavior can prevent normal operation after a power failure).
- If the display works but the oven will not heat, watch for the bake or broil element glowing during preheat.
- If the oven heats inconsistently or shuts off early, suspect a temperature sensing issue.
| Symptom | Likely cause | What to do next |
|---|---|---|
| No heat in Bake, Broil works | Bake circuit issue | Inspect wiring and connections; consider replacing the bake element if damaged |
| No heat in Broil, Bake works | Broil circuit issue | Consider replacing the broil element if it is blistered or broken |
| Oven heats but temperature is wrong | Sensor out of range | Test/replace the frigidaire range oven temperature sensor 316490000 |
| Control responds oddly after outage | Power interruption behavior | Reset clock and cooking function; reprogram settings |
These are common failure points for heating and temperature control on model 79096569602:
- Frigidaire range oven temperature sensor 316490000 (temperature feedback to the control)
- Frigidaire range bake element 316413800 (primary heating in Bake)
- Frigidaire range broil element 316203301 (top heating in Broil)
When an electric oven stops working, the fix depends on whether the problem is power, heat generation (elements), or temperature control (sensor/control). Checking symptoms first helps you replace the right part and avoid repeat failures.
Last updated: February 2026
