Kenmore 25328452805 freezer Parts

The Kenmore upright freezer model 25328452805 size is defined by its capacity (cubic feet) and its cabinet dimensions (height, width, depth). For this model, the Use & Care Guide confirms operation and features but does not list capacity or exterior dimensions in the excerpted pages; we recommend checking the specifications section in the 25328452805 owner's manual.

When customers ask for freezer size, it typically refers to one of these:

• Capacity: cubic feet of storage (used for shopping and food planning)
• Exterior dimensions: width, height, depth (used for fit and clearance)
• Interior layout: shelves, bins, baskets (used for organization)

Use these quick checks to get the exact numbers for your specific unit:

• Look in the specifications section of the 25328452805 owner's manual
• Check the model and serial number plate inside the freezer (upright models are typically on the upper left interior wall)
• Measure the cabinet with a tape measure (width, height, depth), then add clearance space for airflow

• Measure width at the widest point (often the hinge side)
• Measure depth with the door closed; note that handles can add depth
• Measure height from floor to top; include hinge cover if present

Most Kenmore upright freezers in this style fall into these common ranges.

Getting the correct size helps prevent installation problems (door swing and clearance), improves airflow for consistent temperatures, and avoids overfilling that can restrict circulation and cause warm spots or frost buildup.

Last updated: January 2026

Yes. On Kenmore upright freezer model 25328452805, the control panel includes an ALARM RESET button that silences the “Hi TEMP” alarm and buzzer after a warm-temperature event. This button is for the alarm; it is not a full “factory reset” for the freezer’s electronics (see the 25328452805 owner's manual).

When the freezer is first plugged in, or if the inside temperature rises above about 23°F, the “Hi TEMP” indicator can turn on and the buzzer can sound. Pressing ALARM RESET stops the buzzer so you can address the cause of the warm temperature.

• Silences the “Hi TEMP” buzzer when the freezer is too warm
• Helps confirm the alarm is responding normally
• Does not repair cooling problems by itself
• Does not replace unplugging the unit to restart it

If you are trying to clear a glitch or restart cooling, a power reset is the most reliable approach.

1. Turn the temperature control to OFF (if your control has an OFF position).
2. Unplug the freezer for 5 minutes.
3. Plug it back in and set the temperature back to your normal setting.
4. Allow 24 hours for temperatures to stabilize.

An “E” on the temperature display indicates a fault condition that needs service-level diagnosis. We recommend checking the error meaning first, then troubleshooting the related circuit.

• Use the Kenmore electronic control module freezer error codes reference to identify the code family
• Inspect door sealing and airflow first (blocked vents, overpacked shelves)
• If the freezer is warm and the evaporator fan is not running, check the freezer evaporator fan motor 297309000

Using the correct “reset” prevents unnecessary part swaps. The alarm reset handles nuisance buzzing after a warm event, while a power reset helps recover from a control hiccup. If the freezer is still warm afterward, the issue is usually airflow, defrost, or a control/fan problem.

Last updated: January 2026

On Kenmore upright freezer model 25328452805, the model and serial number plate is located on the upper left wall inside the freezer. This is the fastest place to check when you need the correct parts, diagrams, or service information; see the 25328452805 owner's manual for the “Record your model and serial numbers” section.

Check these spots in order:

• Upper left interior wall inside the freezer (primary location for upright models)
• Interior side wall near the front opening (if the label was placed lower)
• Left exterior wall (more common on chest models, but worth a quick check)
• Behind the lower base panel or kick plate area (some designs place labels near the bottom)

• Open the door and scan the upper left interior wall first
• Use a flashlight; labels can be hard to read in low light
• Wipe away frost or residue so the print is readable
• Record both the model number and serial number exactly as shown
• Take a clear photo for parts ordering and future reference

Kenmore freezers can have small production changes that affect fit. Using the exact model number from the plate helps us match the right parts the first time, such as a freezer door gasket, electronic control, or defrost heater.
