Kenmore 79551319013 refrigerator Parts

On the Kenmore 79551319013 side-by-side refrigerator, the model number is printed on the appliance identification label (the same label that lists the serial number). You will typically find this label inside the fresh food compartment along the side wall or near the ceiling.

Most common label locations to check

Look in these spots first (use a flashlight and check both compartments):

• Fresh food section: left or right interior side wall
• Fresh food section: near the top, behind the top shelf area
• Fresh food section: on the frame around the door opening
• Freezer section: interior side wall (less common, but possible)
• Back of the unit near the lower service area (least common)

What the label looks like and what to copy down

The ID label usually includes both the model number and serial number. For parts lookup and troubleshooting, we recommend writing down:

• Model number (for this unit: 79551319013)
• Serial number (unique to your refrigerator)
• Electrical ratings (voltage/amps), if listed

Quick ID guide

Item	What it’s used for	Example
Model number	Matching the correct parts diagrams and parts	79551319013
Serial number	Identifying production run details	Varies

Why it matters

Using the exact model number helps us match the correct Kenmore refrigerator parts for your configuration, including dispenser and ice maker components. Even small model-number differences can change which door bins, gaskets, sensors, or control boards fit.

Next step

Once you find the label, compare the model number to what’s shown in the owner's manual to confirm you are using the correct identifier.

Last updated: February 2026

To replace the ice maker in your Kenmore 79551319013 side-by-side refrigerator, we shut off the water supply, remove the ice bin and mounting screws, disconnect the wiring harness and fill tube, then install the replacement ice maker and restore water and power. Use the owner's manual for model-specific access panels and screw locations.

Before you start (safety and prep)

• Unplug the refrigerator (or switch off the breaker).
• Turn off the water supply valve to the refrigerator.
• Empty the ice bin and remove it from the freezer door.
• Protect the floor with towels; a small amount of water can spill.
• Use a 1/4-inch nut driver or Phillips screwdriver (common on Kenmore side-by-sides).

Replacement steps (typical for Kenmore side-by-side)

1. Remove the ice bin and any shelves/buckets blocking access.
2. Remove the ice maker cover (if equipped) and the mounting screws.
3. Carefully pull the ice maker forward.
4. Disconnect the wiring harness plug.
5. Separate the ice maker from the fill tube area (do not force the plastic fill tube).
6. Transfer any bracket, shutoff arm, or wire guide from the old unit to the new one if the parts match.
7. Mount the new ice maker, reconnect the harness, and reinstall the cover.
8. Turn water back on, plug in the refrigerator, and confirm the ice maker cycles.

What to check if it still will not make ice

• Water supply: Confirm the shutoff valve is fully open and the supply line is not kinked.
• Fill tube: Make sure it is seated and not frozen shut.
• Freezer temperature: Target about 0°F; warm freezers slow or stop ice production.
• Ice clumps/jams: Dump old ice and confirm the bin seats fully.
• Dispenser door issues: If the chute door does not close, warm air can cause frosting and ice problems; inspect the refrigerator auger motor EAU59551204 area if the dispenser mechanism is acting up.

Parts that commonly come up with ice maker replacement

Symptom	Common area to inspect	Example part on this model page
No ice, freezer cold	Ice maker assembly	Lg refrigerator ice maker assembly 5989JA1002D
Ice dispenses poorly or jams	Auger/dispenser mechanism	Refrigerator auger motor EAU59551204
Frost buildup affecting ice	Door seal and air leaks	Freezer door gasket (model-specific)

Why it matters

A correctly installed ice maker and properly seated fill tube prevent leaks, reduce frost buildup, and help the dispenser deliver consistent ice. Small alignment issues can cause repeated jams or slow ice production.

Last updated: February 2026

If your Kenmore 79551319013 side-by-side refrigerator is warm and the compressor won’t stay running (clicks on and off), runs nonstop with little cooling, or is unusually hot, the compressor or its start components are failing. Rule out airflow and fan issues first.

Signs that strongly point to a compressor or start failure

Look for a pattern of symptoms, not just one:

• Both freezer and fresh food sections warming at the same time
• Repeated clicking every few minutes (start attempt then shutoff)
• Compressor runs for long periods but temperatures barely change
• Compressor shell very hot after repeated start attempts
• Condenser fan runs but cooling stays poor

Checks to do before blaming the compressor

These quick checks often reveal a simpler cause:

• Clean condenser coils; heavy dust can mimic a weak compressor
• Confirm the condenser fan runs when the compressor runs
• Listen for the evaporator fan in the freezer; no airflow means poor cooling
• Check door gaskets for gaps that cause constant run time
• Look at the evaporator frost pattern; a full, even frost is normal, a bare coil with no frost points to a sealed-system problem

Quick decision guide

What you observe	Most likely cause	Next step
Clicks, won’t stay on	Start device/overload or locked compressor	Test start components; sealed-system service if needed
Runs but both sections warm	Sealed-system issue or airflow restriction	Verify fans, coils, frost pattern
Freezer cold, fridge warm	Airflow/damper issue	Check vents and damper operation

Why it matters

A compressor is part of the sealed cooling system; confirming airflow and fan operation first prevents replacing a major part when the real issue is a fan, dirty coils, or an airflow restriction.

Parts that may be involved on this model

• Refrigerator compressor TCA35931727
• Refrigerator evaporator fan motor 4681JB1029S

For component locations and access steps, use the owner's manual.

Last updated: February 2026
