Installing the auxiliary handle and depth gauge on your Craftsman pneumatic drill driver

• Disconnect the air supply to the pneumatic drill driver. Wear work glove to protect your hands.
• Slide the depth gauge into the mounting hole on the grip clamp.
• Slide the grip clamp and the auxiliary handle onto the drill collar and turn the handle until it's tight.
• Rotate the handle to the desired position. You can rotate the handle 180-degrees to the depth gauge can be used on either side of drill driver housing.

Common repair parts for Craftsman pneumatic drill drivers

• Spindle lock pin. The spindle lock pin prevents the chuck from turning while installing and removing bits.
• Trigger switch. The hammer drill trigger switch starts and stops the drill driver and controls the speed of the drill.
• Auxiliary handle. The auxiliary handle helps you grip and control the drill driver.
• Drill chuck. The drill chuck holds the drill bit or socket on the drill driver.
