Craftsman Hammer drills

Official Craftsman hammer drill parts

Craftsman hammer drills are known for their rugged durability and top performance. Complete any masonry drilling project using your Craftsman hammer drill. When parts wear out or break on your Craftsman hammer drill, you can find the genuine Craftsman replacement parts you need at Sears PartsDirect.

Safety advice for your Craftsman hammer drill

  • Operating your hammer drill typically results in foreign objects being thrown about. These foreign objects can get thrown into your eyes. Before using your hammer drill, always wear safety goggles to protect your eyes.
  • Wear work gloves to protect your hands when using your hammer drill.
  • Keep your work area clean and well lit.
  • Keep children and bystanders away from the work area when using your hammer drill.

Common replacement parts for Craftsman hammer drills

  • Carbon motor brush set. The carbon motor brush set contains the carbon motor brushes that transfer electric current to the spinning armature in the motor.
  • Chuck and spindle assembly. The chuck and spindle assembly includes the chuck that holds the drill bit and the spindle that turns to rotate the bit.
  • Compression spring. The hammer drill compression spring applies tension against the directional selection lever as it moves up or down and holds the lever in the position selected.
  • Shell assembly. The shell assembly houses the switch and drive components, and forms the outer body of the hammer drill.
