Craftsman 917377011 lawn mower Parts

On the Craftsman walk-behind mower model 917377011, the model number is typically printed on a product label on the mower deck; check the rear area of the deck near the lower handle mounting points. Confirm the full number exactly as shown in the 917377011 owner's manual.

Check these common label locations first (clean the area if needed):

• Back of the mower deck, between or near the lower handle mounts
• Rear of the deck, just above the discharge opening or rear door area
• Side of the deck near the rear wheel height adjuster
• Under the rear flap or grass bag door area (if equipped)

Dirt, grass residue, and sun fading can make the sticker hard to read. These steps usually help:

• Wipe the label with a damp rag and mild soap; avoid harsh solvents
• Use a flashlight at an angle to make faint printing stand out
• Take a close-up photo and zoom in to read worn characters
• Write down the full model number and any serial number on the same label

We use the model number to match the correct Craftsman parts diagrams and ensure you get the right drive components, wheels, blade adapter, and hardware for your exact deck and transmission setup.

Last updated: January 2026

For Craftsman lawn mower model 917377011, use fresh, clean, regular unleaded gasoline with a minimum of 87 octane. Using 91 octane is not required for normal operation; fuel freshness and proper storage matter more than higher octane for this mower (see the 917377011 owner's manual).

• Use regular unleaded gasoline (87 octane minimum).
• Buy fuel you can use within 30 days to keep it fresh.
• Do not mix oil with gasoline.
• Avoid old fuel and contaminated fuel (water, dirt, rust).
• Be cautious with alcohol-blended fuels (ethanol/methanol); they can attract moisture during storage.

Higher octane does not add power in a mower designed for regular fuel. It mainly helps prevent knock in high-compression engines.

If you have hard starting, surging, or stalling, fuel quality is a top suspect.

• Drain the tank and refill with fresh 87+ octane fuel
• Check the air filter and spark plug condition
• Inspect for water in fuel (milky look, phase separation)
• If the engine won’t start and the blade area is involved, check for a loose blade or damaged adapter

If you’re servicing the blade area, a worn adapter can cause vibration and starting issues; match parts by model and diagram, such as the lawn mower blade adapter 532186766.

Using the correct fuel (87+ octane) and keeping it fresh helps prevent carburetor varnish, corrosion from moisture, and no-start problems after storage. For seasonal storage steps, follow the fuel system guidance in the 917377011 owner's manual.

Last updated: January 2026

The model number for this Craftsman walk-behind gas lawn mower is 917.377011 (often written without the dot as 917377011). You can confirm it on the mower’s model tag and in the 917377011 owner's manual.

We recommend checking these common locations first:

• On the rear of the deck near the discharge opening or rear door
• On the handle bracket area near the height adjusters
• Near the engine mounting area on the deck
• On a sticker or metal tag that also lists serial information

Use these quick identifiers to match the mower to the manual and parts diagrams:

• Model format: 917.377011 (or 917377011)
• Mower type: rotary lawn mower, power-propelled
• Deck size: 21-inch multi-cut
• Engine family shown in manual: 675 Series Briggs & Stratton

We use the model number to match the correct parts list and diagrams for your mower. Even small model changes can affect items like the drive control assembly, wheels, blade adapter, and hardware.

Last updated: January 2026
