Kenmore 25324752104 freezer Parts

On the Kenmore upright freezer model 25324752104, the model and serial number label is typically on the upper left wall inside the freezer compartment. This is the most common location for upright models and is the first place we recommend checking in your 25324752104 owner's manual.

Look for a paper or metal serial plate, usually near the door opening:

• Upper left interior wall (most common for upright models)
• Side wall inside the cabinet, near the front edge
• Ceiling area inside the freezer (some upright designs)
• Behind the lower kick plate or base grille (if your model has one)
• Back exterior panel (less common, but possible)

• Use a flashlight; the label can blend into the liner.
• Check near the door gasket line; labels are often placed where they are protected.
• Wipe frost or condensation off the liner so the print is readable.
• Record both the model number and serial number before ordering parts.

We use the exact model number to match the correct Kenmore freezer parts list, including items like the defrost system, temperature control components, and door gasket.

Last updated: January 2026

Kenmore upright freezer model 25324752104 typically does not use a single dedicated “reset button.” Most reset situations are handled by restoring power (unplugging briefly) and then re-setting the temperature control inside the cabinet, as outlined in the 25324752104 owner's manual.

• Turn the temperature control to OFF.
• Unplug the freezer from the wall outlet.
• Wait 5 minutes (this lets the control and compressor protection reset).
• Plug the freezer back in.
• Set the temperature control back to a normal setting and allow several hours for temperatures to stabilize.

These checks help separate a control issue from an airflow or defrost problem:

• Confirm the freezer is plugged into a grounded outlet (no extension cord or adapter).
• Make sure the door is closing and sealing; a poor seal can cause warm temps and frost.
• Listen for the evaporator fan; if it is not running, airflow across the evaporator can stop.
• Check for heavy frost on the back interior panel; that often points to a defrost system problem.
• If your model has a rapid freeze switch, verify it is set the way you want (it must be turned off manually).

A “reset” only restores normal operation if the freezer shut down due to a temporary control lockup or compressor protection. If a defrost failure, door sealing problem, or fan issue is present, the freezer will quickly return to warm temperatures or frost over again.

Last updated: January 2026

The exact cubic-foot capacity for Kenmore upright freezer model 25324752104 is listed on the model’s rating information in the documentation; check the 25324752104 owner's manual for the official capacity value for your specific unit.

We recommend using the manual first because it ties the capacity to the correct model and configuration.

• Look in the specifications or “features” section for “capacity” or “cu. ft.”
• Check the model and serial tag location described in the manual (upright models are typically labeled on the upper left interior wall)
• Match the model number exactly: 25324752104
• If your freezer has a control module that shows codes, use the model-specific error code resources to confirm you are working with the right platform

Cubic feet is the interior storage volume of the freezer compartment. It helps you compare storage space between upright freezers and plan shelving, baskets, and bulk food storage.

Knowing the correct capacity helps us recommend the right organization accessories and troubleshoot issues like overloading, airflow restrictions, and temperature swings that can lead to frost buildup.

If your freezer uses an electronic control and you’re seeing a code, use Kenmore electronic control module freezer error codes to identify the issue before replacing parts.

Last updated: January 2026
