Kenmore 2537034341D refrigerator Parts

To tell what Kenmore refrigerator model you have, find the model and serial number label on the cabinet liner inside the fresh food section or freezer area. For Kenmore model 2537034341D, the label is typically inside the compartment, not on a removable part.

Where to look for the model number label

Check these common spots first (use a flashlight and look for a sticker or metal tag):

• Inside the refrigerator compartment on a side wall near the crisper drawers
• Inside the refrigerator compartment on the ceiling near the light housing
• Inside the freezer compartment on a side wall or back wall
• Behind the toe grille (kick plate) at the bottom front (less common)
• On the hinge-side door frame area (open the door and look along the frame)

What you should write down

The label usually includes more than just the model number. Capture all of this so we can match parts correctly:

• Model number (example format: 253.7034341D or 2537034341D)
• Serial number (needed for some part variations)
• Electrical rating (volts/amps, sometimes listed)

Quick check: model number formats

Kenmore refrigerator model numbers are often shown with or without a dot. These are the same model when the digits match.

On the label	How it may appear online	What it means
253.7034341D	2537034341D	Same model; punctuation varies
253.7034341	2537034341	Incomplete; re-check for the final letter

Why it matters

We use the exact model number (and sometimes the serial) to match the correct Kenmore parts list, diagrams, and compatible items like a water filter, ice maker, or door gasket. That prevents ordering a part that looks right but does not fit.

Helpful next step

If you are also installing or moving the refrigerator, follow the safety and setup steps in the 2537034341D installation guide before reconnecting power or the water line.

Last updated: February 2026

Your Kenmore bottom-mount refrigerator model 2537034341D is about 26 cubic feet of total capacity. For the most accurate capacity listing tied to your exact configuration, we recommend confirming it in the 2537034341D owner's manual.

How to confirm capacity for your exact 2537034341D

Capacity can vary slightly by configuration (shelves, bins, and ice maker setup). The most reliable way to confirm is to check the specifications section in the manual.

• Look for a section labeled Specifications, Product dimensions, or Capacity
• Confirm whether the value shown is total, refrigerator, or freezer capacity
• If your unit has an ice maker, note that installed accessories can reduce usable space
• Record your model and serial from the rating plate inside the fresh food compartment

What “26 cu. ft.” means in real use

“Cubic feet” is the internal volume measurement; it helps compare overall storage size across refrigerators.

Capacity type	What it describes	What you notice day to day
Total capacity	Combined refrigerator + freezer space	Overall size comparison
Usable space	Space after shelves, bins, ice maker	How much you can actually fit
Refrigerator section	Fresh food compartment volume	Grocery and beverage storage

Why it matters

Knowing the cubic feet helps when you are matching replacement parts (like shelves and bins), planning kitchen fit, or comparing performance expectations for a bottom-mount refrigerator.

Related maintenance tip

If your 2537034341D has a water and ice system, staying on schedule with filter changes helps keep flow and taste consistent. The manual notes typical replacement intervals and status prompts; see the Kenmore refrigerator water filter 9999 if you are shopping for the filter.

Last updated: February 2026

On Kenmore model 2537034341D, there is no separate “reset button” for the bottom-freezer ice maker; the practical reset is to turn the ice maker OFF, then back ON, and clear any water or bin issues so the ice maker can restart a normal harvest cycle. For the exact ice maker controls and locations, follow the 2537034341D owner's manual.

Quick reset steps (bottom-freezer ice maker)

• Pull the freezer drawer open to access the ice maker.
• Lift the wire signal arm up to turn the ice maker OFF.
• Wait 2 to 5 minutes.
• Lower the wire signal arm down to turn the ice maker ON.
• Make sure the ice bin is pushed fully to the rear so it does not hold the arm up.
• Allow up to 24 hours for normal ice production after restarting (especially after installation or a long outage).

If it still will not make ice

These are the most common “no ice” causes after a reset:

• Household water valve is closed, or the refrigerator is not connected to water
• Supply line is kinked behind the refrigerator
• Water filter is not seated fully, or is clogged/older than about 6 months
• Wire signal arm is blocked by food packages or the ice bin position
• Air trapped in the water line after a filter change

If you suspect a water supply problem, we often see the water inlet valve as a root cause; for this model, check the refrigerator water inlet valve assembly 242253002.

What to expect after a reset

Situation	What you should see	What to do
First-time use or after filter change	Early cubes can look cloudy or taste odd	Discard the first full bin (or first two full bins on counter-depth units)
After power outage	Cubes may melt and refreeze into clumps	Remove bin, break up clumps, clean and dry bin
Normal operation	Cycling sounds during fill and harvest	This is expected during ice making

Why it matters

Resetting by cycling the wire signal arm restores normal operation without forcing the ice maker to run while the water line, filter, or bin position is still preventing proper fills and harvests.

Last updated: February 2026

A bad compressor on your Kenmore 2537034341D bottom-mount refrigerator typically shows up as poor cooling, nonstop running, unusual noises, or repeated power issues. Before condemning the compressor, we rule out power supply problems, airflow restrictions, and control or sensor issues using the checks in the 2537034341D owner's manual.

Quick signs the compressor is failing

• Refrigerator and freezer temperatures keep rising even though the unit runs
• Compressor runs almost constantly and still cannot maintain set temps
• Clicking or buzzing at the compressor area followed by the unit stopping
• Compressor shell is extremely hot and the refrigerator struggles to cool
• Breaker trips or the unit repeatedly shuts off (after confirming the outlet is correct)

What to check first (common look-alikes)

Many “bad compressor” symptoms are caused by power, airflow, or temperature-sensing problems.

• Power and voltage: Use a properly grounded 3-prong outlet; avoid extension cords, adapters, and GFI circuits. Low voltage can damage the compressor.
• Air circulation: Make sure the toe grille is not blocked and the refrigerator has room to breathe.
• Room temperature: Do not install where temps drop below 55°F or rise above 110°F; the compressor cannot maintain proper internal temperatures.
• Evaporator fan airflow: If the freezer is cold but the fresh food section is warm, airflow can be the issue; inspect the refrigerator evaporator fan blade 5308000010.
• Temperature sensing/control: A failed sensor can cause incorrect run times; this model uses temperature sensors such as refrigerator temperature sensor 5303918775.

Symptom-to-likely-cause guide

What you notice	More likely cause	Compressor more likely when
Warm fridge and warm freezer	Sealed system, compressor, or control issue	Compressor runs but cooling never improves
Freezer cold, fridge warm	Airflow/evaporator fan/ducting	Fan is running and airflow is strong but fridge stays warm
Clicking every few minutes	Start device, overload, power issue	Proper power is confirmed and clicking persists
Runs constantly	Dirty condenser area, warm room, door seal leak, sensor	Airflow, seals, and sensors check out and temps still climb

Why it matters

A compressor is the heart of the sealed system; replacing it is a major repair. Doing the quick power, airflow, and sensor checks first prevents unnecessary parts replacement and helps you pinpoint the real failure faster.

Last updated: February 2026

Most Kenmore refrigerators, including the Kenmore 2537034341D bottom-mount style, typically last 12 to 15 years with normal household use. Consistent cleaning, correct installation conditions, and good airflow help the compressor and cooling system run longer; see the 2537034341D owner's manual for model-specific care guidance.

What affects refrigerator lifespan the most

A refrigerator’s life is usually determined by how hard the sealed system and fans have to work day to day.

• Keep the toe grille area clear so air can circulate properly (blocked airflow makes the unit run hotter).
• Install the refrigerator where room temperature stays roughly 55°F to 110°F.
• Avoid frequent, long door openings; it increases run time and frost load.
• Replace consumables on schedule (water filters and air filters are normal wear items).
• Level and align doors so gaskets seal evenly and do not leak cold air.

Maintenance schedule we recommend

Use this as a practical baseline for the 2537034341D and most Kenmore bottom-mount refrigerators.

Task	Typical frequency	Why it helps
Replace water filter	Every 6 months or about 200 gallons	Protects water flow and ice maker performance
Replace air filter (if equipped)	Every 6 months	Helps reduce odors and keeps airflow cleaner
Clean toe grille and surrounding area	Every 3 to 6 months	Improves cooling efficiency and reduces heat stress
Check door gasket seal	Every 6 months	Prevents warm air leaks and excess run time

If your model uses the Kenmorepure water filter, the manual notes a common replacement interval of about six months. When it is time to replace it, match the correct part for this model, such as the Kenmore refrigerator water filter 9999.

Why it matters

A refrigerator that runs hotter or longer than designed wears out key components faster (compressor, evaporator fan, control board). Good ventilation and a tight door seal reduce run time, which is the simplest way to extend service life.

Last updated: February 2026

Kenmore is a brand; the replacement parts used on Kenmore model 2537034341D are produced by the original equipment manufacturer (OEM) that built that specific refrigerator design and its components. The most accurate way to identify the maker and get the right fit is to match your model number and the exact part number shown in the 2537034341D owner's manual.

How we identify the correct manufacturer for your part

For model 2537034341D, the part listing details (part number, description, and fit notes) are the practical way to confirm what you need.

Use these checks:

• Confirm the full model number: 2537034341D
• Match the part number from the diagram or list to the part you are replacing
• Compare the part name and where it installs (freezer drawer, fresh food section, dispenser)
• For water and ice parts, verify your refrigerator uses that feature (filter housing, ice maker, inlet valve)

Examples of model-matched parts for 2537034341D

These examples show how different components are sourced and identified by their part IDs and numbers.

Part type	Example part for this model	What it affects
Water filter	Kenmore refrigerator water filter 9999	Water taste, flow, ice quality
Ice maker	Refrigerator ice maker 243297613	Ice production and harvesting
Water inlet valve	Refrigerator water inlet valve assembly 242253002	Water supply to dispenser and ice maker

Why it matters

Using the correct OEM-matched part prevents fit problems, leaks, poor cooling performance, and repeat repairs. It also keeps troubleshooting accurate because symptoms often point to a specific component, not the whole refrigerator.

Quick tips before you order

• Use the part number from the model parts list, not just a description
• Replace filters on schedule; most refrigerator water filters are changed about every 6 months
• Follow safety steps before servicing; unplug power before working near wiring or controls
• For installation and leveling details, use the 2537034341D installation guide

Last updated: February 2026

Water pooling inside the bottom of your Kenmore 2537034341D refrigerator is usually caused by a defrost drain problem (water cannot flow to the drain pan), warm air leaking past a door gasket, or excess moisture from food and containers. Use the 2537034341D owner's manual to confirm normal moisture vs. a true leak.

Quick checks that solve most pooling issues

• Wipe it dry, then watch where water returns first (back wall, under crisper, near door).
• Check the door seal for gaps, tears, or areas that do not grip paper when the door is closed.
• Look for ice or sludge at the bottom rear inside the fresh food section (common sign of a clogged defrost drain).
• Confirm food is covered and containers are not sweating or dripping.
• Level the refrigerator so doors close firmly; poor closing increases condensation.

Normal moisture vs. a problem (what to expect)

The manual notes that some water in drawers can be normal, especially from produce moisture.

What you see	Most likely cause	What to do first
Water only in crisper drawer bottom	Wet produce or condensation	Dry produce, lower humidity setting if equipped
Water on fridge floor under drawers	Defrost drain restricted	Clear drain area and flush with warm water
Water near door edges	Door not sealing or not closing	Inspect gasket, level unit, reduce door-open time
Water after filter change	Small spill during replacement	Wipe up; recheck filter seating

Parts that commonly relate to this symptom

If you confirm a component issue, these model-matched parts are common suspects:

• Frigidaire refrigerator door gasket (white) 241778315 (warm air leaks cause sweating and puddles)
• Frigidaire refrigerator freezer door gasket (gray) 5304537408 (freezer air leaks can drive frost and defrost water)
• Kenmore refrigerator water filter 9999 (a loose or mis-seated filter can drip right after service)

Why it matters

Pooling water can lead to ice buildup, odors, and temperature swings. Fixing airflow leaks (gaskets) and keeping the defrost drain flowing helps the evaporator and compressor maintain stable cooling.

Last updated: February 2026
