Kenmore 25328452808 freezer Parts

On Kenmore upright freezer model 25328452808, the model and serial number plate is typically located on the upper left wall inside the freezer compartment. This is the primary location to check before looking elsewhere on the cabinet.

Check these areas in this order:

• Upper left interior wall inside the freezer (most upright models)
• Along the inside side wall near the front opening
• Near the ceiling area inside the freezer (some uprights)
• Behind the lower kick plate or base panel (if your model has one)
• On the back exterior panel of the cabinet

For the exact location and how the plate is labeled, use the 25328452808 owner's manual.

The plate usually lists both identifiers you need for parts and service:

Using the correct model number prevents ordering the wrong Kenmore freezer parts (like a door gasket, evaporator fan motor, or defrost heater) that may look similar but fit differently across model variations.

Last updated: February 2026

You can’t determine cubic feet from a Kenmore model number alone; you confirm capacity by checking the model’s specifications in the 25328452808 owner's manual. If you need a quick estimate, we calculate cubic feet by measuring the inside usable space (width × height × depth) and dividing by 1,728.

Use interior measurements in inches (not the outside cabinet size).

• Empty the freezer so you can measure accurately.
• Measure interior width, interior height, and interior depth (in inches).
• Multiply: W × H × D = cubic inches.
• Divide by 1,728 to convert cubic inches to cubic feet.
• Round to the nearest tenth for a practical estimate.

For Kenmore model 25328452808, the most accurate capacity is the published specification in the 25328452808 owner's manual. That spec reflects the manufacturer’s rated storage volume, which can differ from a tape-measure estimate because shelves, bins, and interior contours reduce usable space.

Capacity affects how much food you can freeze at one time. The manual guidance is to freeze about 3 pounds of fresh food per cubic foot of freezer space at one time, which helps the freezer pull temperatures down safely.

Last updated: February 2026

Ice buildup in your Kenmore 25328452808 upright freezer is almost always caused by warm, moist air getting inside (door not sealing, door opened often) or by a defrost/drain issue. We stop icing by restoring a tight door seal, keeping the door closed, and making sure the defrost drain is closed and draining correctly per the owner's manual.

• Make sure the door closes fully every time; avoid propping it open while loading.
• Level the freezer so the door seals correctly (a slightly “front higher” stance helps the door close on its own).
• Check the door gasket for gaps, rips, or areas that are stiff and not contacting the cabinet.
• Confirm the internal drain plug is installed after defrosting; an open drain lets warm air in.
• Keep airflow clear inside; don’t pack items tight against interior vents.
• Scrape light frost occasionally with a plastic scraper (never metal).

The manual guidance is to defrost and clean when frost reaches about 1/4 to 1/2 inch.

Basic steps:

• Unplug the freezer.
• Remove food and leave the door open.
• Pull the inside floor drain plug straight out (upright models with a defrost drain).
• Route water to a shallow pan at the external drain tube (behind the base panel on some models).
• Reinstall the drain plug when finished.

If the door is closing but frost returns quickly, a failed door seal or a door switch issue can contribute.

Model-matched parts commonly involved:

• Freezer door gasket 5304507201
• Freezer door switch 216822900

Excess frost acts like insulation on cold surfaces and restricts airflow, so the freezer runs longer, temperatures swing more, and food quality can suffer.

Last updated: February 2026

Kenmore upright freezer model 25328452808 does not use a general “reset button” for operation. What you do have is an ALARM RESET button that silences the Hi Temp alarm and buzzer after the freezer temperature returns to a safe range; see the 25328452808 owner's manual.

On this model’s electronic temperature control, the freezer can sound a buzzer and light the Hi TEMP indicator when the inside temperature is above about 23°F. The ALARM RESET button:

• Silences the buzzer when the Hi TEMP alarm is active
• Does not repair a cooling problem or “reboot” the freezer
• May need to be pressed again if the buzzer repeats (for example, after another warm-up event)
• Helps you confirm whether the freezer is still warming up or has recovered

If the freezer is acting up (warm temps, alarm, no cooling), these steps address the most common causes:

• Power cycle: unplug the freezer for 5 minutes, then plug it back in
• Confirm temperature setting: set the control back to your normal setting (many users target about 0°F)
• Check door seal and closure: look for gaps, torn gasket, or items blocking the door
• Listen for airflow: a failed evaporator fan can cause warm temps and uneven cooling
• Defrost heavy frost: if frost buildup is thick, defrosting restores airflow and cooling performance

If the freezer will not recover temperature, these model-matched parts are commonly involved:

• Freezer evaporator fan motor 297309000 (moves cold air through the cabinet)
• Freezer door gasket 5304507201 (prevents warm air leaks)
• Freezer defrost heater 5304496687 (helps prevent frost that blocks airflow)

The Hi Temp alarm is a food-safety warning. Using ALARM RESET correctly helps you stop nuisance buzzing while you focus on the real issue: restoring stable freezer temperature and airflow.

Last updated: February 2026

A Kenmore upright freezer like model 25328452808 lasts 10 to 15 years. With steady temperatures, good airflow, and routine cleaning, it reaches the full lifespan and avoids early failures tied to frost buildup, door leaks, and overheating.

Most upright freezers fall into the same lifespan range, but these factors make the biggest difference:

• Door seal condition (air leaks force longer run times)
• Condenser cleanliness (dust raises compressor heat)
• Frost control health (heavy frost reduces airflow and cooling)
• Room temperature and ventilation (hot garages shorten life)
• How often the door is opened (warm air adds moisture and load)

Use these habits from the care and operating guidance in the owner's manual:

• Keep the door closed as much as possible; organize food to reduce search time
• Do not line shelves with foil or paper; it blocks cold-air circulation
• Allow a full cool-down period before loading unfrozen food (about 4 hours after startup)
• Clean the cabinet and interior with mild detergent; dry thoroughly
• During long storage, leave the door slightly open to prevent odors and mold

A freezer that is running longer than normal uses more electricity and puts extra wear on the sealed system (compressor, evaporator, condenser). Simple upkeep, especially keeping airflow clear and the door sealing tightly, is what protects that 10 to 15 year service life.

Last updated: February 2026
