Model #2538791223 Official Kenmore refrigerator
Here are the diagrams and repair parts for Kenmore 2538791223 refrigerator, as well as links to manuals and error code tables, if available.
There are a couple of ways to find the part or diagram you need:
- Click a diagram to see the parts shown on that diagram.
- In the search box below, enter all or part of the part number or the part’s name.
Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.
We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.
For DIY troubleshooting advice and repair guides, visit our repair help section.
Model Diagram and Schematics
Search within this model
?
This is the number corresponding to the part on the diagram / schematic
Parts List
Showing 10 of 244 parts
Refrigerator heater
Part #3206329
Replaced by #241798231
?
Manufacturer substitution
This part replaces 3206329. Substitute parts can look different from the original.
In Stock
$144.32 |
6% OFF
Phone Price: $154.32
Refrigerator fan
Part #174705
Replaced by #5308000010
?
Manufacturer substitution
This part replaces 174705. Substitute parts can look different from the original.
In Stock
$39.39 |
11% OFF
Phone Price: $44.39
Refrigerator ice maker assembly
Part #3206306
Replaced by #5303918277
?
Manufacturer substitution
This part replaces 3206306. Substitute parts can look different from the original.
In Stock
$169.29 |
6% OFF
Phone Price: $179.29
Refrigerator drier
Part #177375
Replaced by #5303305677
?
Manufacturer substitution
This part replaces 177375. Substitute parts can look different from the original.
In Stock
$10.30 |
37% OFF
MSRP: $16.34
Thermostat
Part #162690-01
Replaced by #5303917954
?
Manufacturer substitution
This part replaces 162690-01. Substitute parts can look different from the original.
In Stock
$23.79 |
17% OFF
Phone Price: $28.79
Refrigerator gasket
Part #186803-13
Replaced by #218730609
?
Manufacturer substitution
This part replaces 186803-13. Substitute parts can look different from the original.
In Stock
$107.82 |
8% OFF
Phone Price: $117.82
Refrigerator switch
Part #187200
Replaced by #5309918806
?
Manufacturer substitution
This part replaces 187200. Substitute parts can look different from the original.
This item is not returnable
In Stock
$22.76 |
18% OFF
Phone Price: $27.76
Refrigerator screw
Part #167103
Replaced by #241710601
?
Manufacturer substitution
This part replaces 167103. Substitute parts can look different from the original.
This item is not returnable
In Stock
$14.19 |
12% OFF
Phone Price: $16.19
Refrigerator screw
Part #181020
Replaced by #241710601
?
Manufacturer substitution
This part replaces 181020. Substitute parts can look different from the original.
This item is not returnable
In Stock
$14.19 |
12% OFF
Phone Price: $16.19
