Samsung RF22R7351SG/AA-00 refrigerator

Samsung RF22R7351SG/AA-00 refrigerator Parts

Here are the diagrams and repair parts for Samsung RF22R7351SG/AA-00 refrigerator, as well as links to manuals and error code tables, if available.

By Schematic
By Part
SELECT DIAGRAM
?

This is the number corresponding to the part on the diagram / schematic

Browse Parts for RF22R7351SG/AA-00 Refrigerators

Samsung REFRIGERATOR RF22R7351SG/AA-00 FAQs

For your Samsung RF22R7351SG refrigerator, the right water filter is the one specified for this exact model and the filter housing it uses. We recommend matching the replacement to the filter cartridge style shown in the RF22R7351SG owner's manual and using only Samsung-provided or Samsung-approved filters to prevent leaks and dispenser problems.

Fast ways to identify the correct filter

  • Check the model number on the rating label inside the fresh food compartment; it must match RF22R7351SG.
  • Remove the current filter and match the cartridge style (how it locks in and the knob/handle style).
  • Use the manual’s “Water filter” section to confirm the correct replacement type for this model.
  • If you use reverse osmosis (RO), confirm your water pressure meets the refrigerator’s requirements before blaming the filter.
  • Avoid third-party filters; unapproved filters can leak and cause water flow issues.

What the manual says about filter choice (and why it matters)

Samsung’s guidance for this refrigerator is to use Samsung-provided or Samsung-approved water filters. Using an unapproved filter can lead to leaking, reduced water flow, and dispenser performance problems.

Quick checklist before you buy

What you check What it tells you What to do next
Filter indicator is red Filter is due Replace the filter, then reset the indicator
Filter is hard to remove Cartridge may be contaminated Shut off water, unlock 1/4 turn, pull straight out
Low water flow after filter change Pressure or restriction issue Verify supply valve is open; check RO pressure and sediment filter
Water does not dispense Lock or filter issue Turn off dispenser lock; confirm approved filter is installed

Why it matters

A correct, approved filter protects water quality and helps prevent leaks that can damage components like the water inlet valve and ice maker system.

Related help: how to replace the water filter in a Samsung refrigerator

Last updated: February 2026

No. Samsung refrigerator water filters are not universal; the correct filter depends on your specific refrigerator model and the filter housing it uses. For Samsung model RF22R7351SG, match the replacement to the filter type listed in the RF22R7351SG owner's manual or printed on your current filter.

How to identify the right filter for your Samsung refrigerator

Use one of these reliable checks before you buy:

  • Read the filter model printed on the existing cartridge (remove it and look at the label)
  • Check the filter section in the RF22R7351SG owner's manual
  • Confirm the filter shape and locking style (twist-lock quarter turn is common)
  • Verify your water supply setup; low pressure can mimic a “bad filter” symptom
  • Avoid off-brand filters; unapproved filters can leak and cause damage

What “not universal” means in practice

Samsung uses multiple filter families across different refrigerator lines. Even if two filters look similar, the seal design and bypass valve can differ, so the wrong one may not fit, may leak, or may restrict water flow.

What you compare Why it matters What to do
Filter model/type Ensures correct fit and seal Match the exact filter type from the manual or old filter
Locking method Prevents leaks and pop-out Confirm the same twist/turn engagement
Water pressure Affects dispenser and ice maker performance Keep supply pressure in the recommended range

Why it matters (leaks, flow, and ice production)

A mismatched filter can cause slow dispensing, weak ice production, or water leaks. Samsung also warns against using unapproved third-party filters because they can leak and damage the refrigerator.

Quick tips after you replace the filter

After installing the correct filter:

  • Shut off the water supply before removal
  • Turn the cartridge counterclockwise about a quarter turn to unlock (common Samsung design)
  • Turn the water back on and flush several cups of water to clear air and carbon fines
  • Reset the filter indicator on the control panel (per the manual)

For ice-related symptoms that continue after a correct filter change, use our guide: why your Samsung fridge stopped making ice and how to fix it.

Last updated: February 2026

Cooling problems are the most common issue we see on Samsung refrigerators, including the Samsung RF22R7351SG; symptoms include a warm fresh-food section, temperature swings, or poor airflow caused by frost buildup, blocked vents, or a fan/defrost-related failure. Start with the basic checks and then use the troubleshooting steps in the RF22R7351SG owner’s manual.

Most common symptoms customers notice

  • Fresh-food section is warm but the freezer seems OK
  • Frost or ice buildup that restricts airflow
  • Refrigerator runs a lot or seems louder than normal
  • Ice maker stops producing ice or makes small/hollow cubes
  • Water dispenser flow is weak or intermittent

Quick checks that fix many “not cooling” complaints

  • Confirm the power cord is fully plugged in and the outlet works.
  • Set the temperature colder and allow 24 hours to stabilize.
  • Make sure interior air vents are not blocked by food packages (blocked vents can cause overcooling or poor circulation).
  • Verify the refrigerator has adequate clearance from walls and cabinets for airflow.
  • If the unit was unplugged, wait at least 5 minutes before plugging it back in.

Common causes and the parts that are often involved

Problem area What you’ll notice Parts that commonly relate
Temperature sensing Temps swing, food spoils, erratic cooling Sensors such as refrigerator temperature sensor DA32-10104N
Airflow in cabinet Warm spots, frost buildup, weak circulation Fan systems and evaporator cover areas
Ice and water system No ice, slow fill, dispenser issues Refrigerator water inlet valve DA62-04027A, refrigerator ice maker assembly DA97-18859A

Why it matters

Cooling and airflow problems can look like a “sealed system” failure when the real cause is simpler, such as blocked vents, incorrect settings, or a failed sensor. Catching it early helps protect food and reduces strain on the compressor.

Helpful DIY guidance

If your main complaint is ice production, we recommend following the steps in why your Samsung fridge stopped making ice and how to fix it to rule out common causes before replacing parts.

Last updated: February 2026

Yes. For the Samsung RF22R7351SG, the built-in filter reminder is designed around about 6 months of use (typically about 300 gallons), because filter media loads up over time and can reduce flow and water quality even if the water still looks clear. See the replacement and reset details in the RF22R7351SG owner's manual.

When you should replace it sooner

Replace the filter earlier than 6 months if you notice any of these common signs:

  • Water tastes or smells off
  • Water flow at the dispenser slows down
  • Ice cubes get smaller or hollow
  • The filter indicator starts blinking/red (your reminder is based on time and usage)
  • You have hard water or high lime scale (filter life is shorter)

What to do right after you change the filter

A new filter needs flushing, and the indicator needs a reset.

  • Shut off the water supply before removing the cartridge
  • Install the new cartridge and restore water supply
  • Flush about 1 gallon of water through the dispenser (roughly 6 minutes)
  • Discard the first 1 to 2 days of ice (or the first 1 to 2 buckets) to clear the line
  • Press and hold Filter Reset for 3 seconds to clear the filter light

Quick reference (what the manual is telling you)

Item Typical target Why it matters
Replacement interval About 6 months Keeps filtration performance and flow consistent
Usage guideline About 300 gallons Heavy use reaches end-of-life sooner
Post-install flush About 1 gallon Clears carbon fines and trapped air
Ice purge 1 to 2 days Clears impurities from the new water path

Why it matters

A saturated filter can restrict water to the dispenser and ice maker, and it can let taste and odor issues creep back in. Replacing on schedule also helps you troubleshoot correctly; if flow is weak after a fresh filter, we focus next on water pressure, the supply line, or the refrigerator water inlet valve DA62-04027A.

Last updated: February 2026

The most commonly replaced refrigerator parts are the ones that handle water flow, airflow, temperature sensing, and door sealing. On a Samsung RF22R7351SG, that typically means items like the water inlet valve, ice maker components, fan motors, temperature sensors, and the electronic control board; shelves and bins also get replaced from everyday wear.

Most common parts customers replace

  • Water filter (and related filter housing components)
  • Door gasket (door seal) and door alignment hardware
  • Ice maker parts (ice maker assembly, ice room fan)
  • Water inlet valve (feeds the dispenser and ice maker)
  • Temperature sensors (thermistors) that report cabinet temperature
  • Fan motors (condenser fan and evaporator-area fans)
  • Electronic control board (when cooling or dispensing functions act erratically)

Examples of common replacements for RF22R7351SG

These are model-matched examples we often see replaced when symptoms point to them:

Symptom you notice Common part category Example model-matched part
Ice stops producing or is irregular Ice maker system Refrigerator ice maker assembly DA97-18859A
No water at dispenser or slow fill Water supply system Refrigerator water inlet valve DA62-04027A
Temps fluctuate or error symptoms appear Temperature sensing Refrigerator temperature sensor DA32-10104N
Warm fridge, noisy rear, poor heat removal Condenser airflow Refrigerator condenser fan motor assembly DA97-15765C
Random cooling issues, display odd behavior Controls Refrigerator electronic control board DA94-04604A

Why these parts fail more often

  • Water and ice parts: mineral buildup, restricted filters, low water pressure, or frozen lines
  • Fans and sensors: normal wear, frost buildup, or airflow blockage from overpacked shelves
  • Door seals and hinges: frequent opening, misalignment, or debris on the gasket sealing surface
  • Control boards: power surges or moisture exposure over time

Before you order a part

We recommend these quick checks first because they often point to the right system:

  • Confirm the unit is on its own dedicated outlet and the plug is seated firmly.
  • Unplug power before servicing or replacing any part.
  • Check for obvious airflow blockage (packed vents, heavy frost, blocked return vents).
  • For water issues, verify the shutoff valve is fully open and the supply line is not kinked.
  • For ice issues, inspect the ice bucket for clumps and confirm the ice maker is turned on.

Why it matters

Replacing the correct “system” part (water supply, ice maker, airflow, sensing, or controls) prevents repeat failures and protects food temperatures. For model-specific component locations and safety steps, follow the RF22R7351SG owner's manual.

Last updated: February 2026
