Samsung RF28HMEDBSR/AA-07 refrigerator Parts

Common RF28HMEDBSR refrigerator problems we see are water leaking, unusual noise (often fan-related), and the fresh food section running too warm. These symptoms usually trace back to airflow issues, a defrost drain problem, or a water supply component that is restricted or leaking; use the RF28HMEDBSR owner's manual to match symptoms to checks.

• Leaking water: clogged/iced defrost drain, loose water line connection, or a seeping inlet valve
• Noisy operation: evaporator fan hitting ice, condenser fan noise, or vibration from leveling/clearances
• Fridge too warm: blocked vents, frost buildup on the evaporator cover, weak fan airflow, or a sensor/control issue
• Ice maker issues (often tied to “too warm” or “leaking”): frozen fill tube, low water pressure, or ice clumps after a power outage
• Door not sealing well: warm air intrusion that causes temperature swings and excess frost

• Confirm settings: 37°F fresh food and 0°F freezer are the typical targets.
• Make sure air vents are not blocked by food packages.
• Check for ice or water under the crisper drawers (common sign of a drain issue).
• Listen for where the noise comes from (freezer rear panel vs. back bottom near the condenser fan).
• After a power failure, dump the ice bucket and cycle the dispenser once to prevent clumped ice from jamming the dispenser.

Catching these symptoms early prevents food temperature swings, reduces frost and ice buildup that can damage fans, and helps avoid repeated ice maker and dispenser jams.

Last updated: February 2026

A Samsung bottom-mount refrigerator like model RF28HMEDBSR has an average lifespan of 13 years. Keeping the condenser area clean, maintaining good door seals, and fixing cooling or ice maker issues early helps you reach that service life with fewer breakdowns.

• Condenser airflow and cleanliness: dust buildup makes the compressor run hotter and longer.
• Door seal condition and door alignment: warm air leaks increase run time and frost.
• Ice maker and water system health: leaks and clogs can cause secondary damage.
• Stable temperatures: frequent warm-ups strain the sealed system.
• Timely replacement of wear parts: fans, sensors, and valves are common service items.

• Vacuum the condenser area and confirm the condenser fan runs smoothly.
• Keep freezer drawers closing fully; avoid overpacking air vents.
• Replace a noisy or stalled fan promptly.
• Watch for puddles or frost patterns that point to airflow or defrost problems.
• Follow the care and cleaning steps in the RF28HMEDBSR owner's manual.

Most refrigerator failures become expensive when they stress the compressor or sealed system. Simple upkeep and fast fixes to airflow, temperature sensing, and water delivery reduce run time and prevent cascading damage.

Last updated: March 2026

Your Samsung refrigerator’s model number is printed on the rating label; on RF28HMEDBSR units it’s typically inside the fresh food compartment along a side wall or near the ceiling. Match the full model number and version code on the label to the parts list for the best fit.

Check these common rating-label locations first:

• Inside the refrigerator (fresh food section) on the left or right interior wall
• On the ceiling area inside the fresh food compartment
• Along the door jamb area (where the door seals against the cabinet)
• Behind the crisper drawers on an interior wall (less common)
• On the back exterior panel near the bottom (least convenient, but possible)

For diagrams and label examples, use the RF28HMEDBSR owner's manual.

Record the information exactly as shown on the label:

• Model number (example: RF28HMEDBSR)
• Version code or revision (often shown after a slash or suffix, such as /AA-07)
• Serial number (helps identify production run)
• Electrical ratings (useful for diagnosing control board, compressor, and fan issues)

Samsung refrigerators can have small design changes across versions; using the exact model and version code helps us match components like the ice maker, water inlet valve, control boards, and door hardware correctly.

Last updated: March 2026
