Samsung RF30BB620012/AA-00 refrigerator Parts

To check the model on your Samsung refrigerator, look for the rating label inside the fresh food compartment (often on a side wall) and read the model number printed on that label. For this unit, the model number format you’re looking for is RF30BB620012; see the owner's manual for label locations and identification details.

Where to find the model and serial label

Most Samsung bottom-mount and French door refrigerators place the rating label in one of these spots:

• Inside the refrigerator compartment on the left or right side wall
• Near the crisper drawer area (side wall or ceiling area)
• On a frame edge that’s visible when a door is open
• Occasionally on the rear exterior panel (less common for everyday access)

What to write down (and why)

When you’re ordering parts or troubleshooting, we recommend recording these items exactly as shown:

• Model number (example: RF30BB620012)
• Version or revision code (often shown after the model on the label)
• Serial number
• Electrical ratings (voltage/Hz/amps), if you’re diagnosing power issues

Quick ID checklist

Item	What it’s used for	Example format
Model number	Matching parts diagrams and assemblies	RF30BB620012
Serial number	Production run identification	Letters plus numbers
Version code	Ensures the correct part variation	Suffix after model

If you’re checking the model for SmartThings setup

The refrigerator manual notes that SmartThings setup may ask you to select a device model in the app. Having the exact model number from the rating label helps you pick the correct refrigerator type and model during registration.

Why it matters

Samsung refrigerators can use different door parts, sensors, fan motors, and water filter housings across close-looking models. Using the exact model number helps prevent ordering the wrong replacement part.

If you need common maintenance parts for this model, you can also match by part number, such as the Samsung refrigerator water filter HAF-QIN. For broader model searches and ordering, use Sears PartsDirect.

Last updated: February 2026

To remove the bottom shelf in your Samsung RF30BB620012 refrigerator, fully open the door, hold the front of the shelf, then gently lift up and pull it straight out. Keep the shelf slightly tilted so it clears the side rails without forcing the glass.

Step-by-step: removing the bottom (glass) shelf

• Remove heavy items first; tempered glass shelves are heavy.
• Fully open the refrigerator door for maximum clearance.
• Place one hand near each front corner of the shelf.
• Gently lift the front edge up just enough to unhook it.
• While keeping the shelf slightly angled, pull the shelf out toward you.
• Avoid lifting the shelf too high; the rear wall can dent.

Reinstalling the shelf correctly

We reinstall shelves by using the hook-and-notch method so the shelf locks in and sits level.

1. Hold the shelf at an angle (front higher than back).
2. Insert the top hook into the top shelf notch.
3. Lower the shelf, then insert the bottom shelf hook into the bottom shelf notch.

For diagrams and model-specific shelf notes, use the owner's manual.

Quick do and don’t table

Do	Don’t
Lift the front edge slightly, then pull out	Yank the shelf forward without lifting
Keep the shelf slightly angled to clear rails	Lift the shelf fully upward into the liner
Use two hands to control the glass	Twist hard or strike the glass

Why it matters

Removing the shelf the right way prevents chipped glass edges, cracked tempered glass, and dents in the refrigerator’s rear wall. It also helps the shelf hooks seat correctly so airflow and temperature stay consistent.

If you need replacement parts for shelf support or interior components, you can shop by model on Sears PartsDirect.

Last updated: February 2026

If your Samsung RF30BB620012 bottom-mount refrigerator is not making ice in the bottom freezer, the most common causes are the ice maker being turned off, the freezer temperature being set too warm, a new installation that has not had enough time (about 12 hours), or a water supply issue. Use the RF30BB620012 owner's manual to confirm the correct ice maker checks and settings.

Quick checks we recommend first

• Make sure the ice maker is turned on.
• Confirm the freezer is set below -18 °C (-0.4 °F) (colder may be needed in warm rooms).
• If the refrigerator was just installed or recently powered back on, wait 12 hours for ice production.
• Verify the household water supply stopcock is open and the water line connection is secure.
• If you hear buzzing and the water line is not connected, turn the ice maker off to stop the buzzing.

Test the ice maker (built-in diagnostic)

Many Samsung ice makers include a test button on the back of the ice maker.

• Press the Test button.
• Listen for the chime when you press it.
• Listen for a second chime; that indicates the ice maker is operating properly.

Ice bucket and jam issues (especially after a power outage)

Ice can clump or jam and stop normal operation, particularly if the unit recovered from a power failure.

What you see	What it usually means	What to do
Ice clumps in bucket	Ice sat too long (often 3+ weeks)	Remove and empty the bucket, then reinstall it fully
Mixed melted and jammed cubes	Power outage recovery	Empty the bucket before restarting ice making
Ice not dispensing	Bucket not seated	Reinsert the bucket so it sits correctly

Parts that commonly relate to “no ice” symptoms

If settings and water supply are correct, these parts are commonly involved in ice-making problems:

• Samsung refrigerator water filter HAF-QIN
• Refrigerator temperature sensor DA32-00070A
• Refrigerator fan motor DA97-20025A

Why it matters

Ice production depends on three basics: correct freezer temperature, steady water flow, and an ice maker that can cycle without jams. Fixing the root cause prevents repeat clogs, weak ice production, and noisy valve buzzing.

You can order replacement parts for your RF30BB620012 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

The most common issues we see with Samsung refrigerators like model RF30BB620012 are cooling problems (warm fridge or freezer, frost buildup, noisy operation) and ice maker or water system troubles. These symptoms usually trace back to airflow, defrost drainage, or temperature-sensing problems; use the owner's manual for model-specific operating and care steps.

Most common symptoms and what they usually point to

• Fridge not cold enough: restricted airflow, dirty door seals, or a temperature-sensing issue
• Freezer frosting up: defrost/drain problem that lets moisture refreeze
• Noisy humming or fan noise: evaporator fan or fan motor area icing up
• Water under the refrigerator: drain tube or drain cap issue
• Ice maker slow or not making ice: water supply restriction, filter restriction, or temperature not cold enough

Quick checks we recommend first (safe, no tools)

1. Confirm doors close fully and nothing blocks interior air vents (blocked vents can cause overcooling or poor cooling).
2. Clean the door gaskets (dirty rubber seals can prevent proper closing and reduce performance).
3. If you recently unplugged the unit, wait at least 5 minutes before plugging it back in.
4. If the unit was just installed or moved, set temps to the coldest setting and allow time for initial pull-down.

Parts that commonly relate to these problems

If troubleshooting points to a failed component, these parts are commonly involved in cooling and water/ice complaints:

Problem area	What it affects	Example part on this model page
Temperature sensing	Erratic temps, warm compartments	Refrigerator temperature sensor DA32-00070A
Airflow (fan)	Warm fridge, noise, uneven cooling	Refrigerator fan motor DA97-20025A
Water flow/ice	Slow dispensing, ice maker issues	Samsung refrigerator water filter HAF-QIN
Drainage	Leaks, ice buildup from poor draining	Refrigerator drain tube kit DA97-04049E

Why it matters

Cooling and ice maker complaints often start as small airflow or drainage issues, then turn into food spoilage, heavy frost, or recurring leaks. Catching the symptom early helps you avoid secondary problems like fan noise from ice buildup or water pooling.

Helpful DIY guidance

For ice maker-specific troubleshooting steps, use why your Samsung fridge stopped making ice and how to fix it.

You can order replacement parts for your Samsung RF30BB620012 from the parts list for this model, or search by model number on Sears PartsDirect.
