Can I look up Frigidaire parts by model number?
Yes. For your Frigidaire free standing gas range model FCFE3083ASB, looking up parts by the full model number is the most accurate way to match diagrams and order the correct replacement parts from the parts list for this model, or by searching on Sears PartsDirect.
- Use the complete model number: FCFE3083ASB (letters and numbers matter).
- Start with the model-specific parts list and diagrams for FCFE3083ASB to avoid mismatches.
- If you are searching more broadly, enter FCFE3083ASB exactly as shown on the model tag.
- Match the part by name and ID before ordering (for example, probe 5304533448).
- If multiple versions appear, choose the one that matches your range’s configuration (finish, burner layout, and control style).
On most Frigidaire ranges, the model/serial tag is typically found in one of these spots:
- Door frame area (around the oven opening)
- Storage drawer frame (pull the drawer out and look along the frame)
- Lower side trim near the front
These are examples of parts shown for FCFE3083ASB on this model’s parts list:
| What you are fixing | Part you may need | Example from this model |
|---|---|---|
| Oven temperature sensing | Temperature probe | Probe 5304533448 |
| Power connection issues | Terminal block | Universal/multiflex (Frigidaire) range terminal block 5303935271 |
| Door not locking for self-clean | Door latch | Latch assemb 5304528257 |
Model-number lookup prevents ordering the wrong Frigidaire range parts because similar-looking ranges often use different wiring harnesses, control boards, switches, and door components. Using FCFE3083ASB keeps the part match tied to your exact appliance.
Last updated: February 2026
Where can I find my Frigidaire oven part number?
Your Frigidaire FCFE3083ASB range does not have one single “oven part number.” Instead, each replacement part has its own part number, and you match the correct one by using the model and serial tag on the range, then selecting the part from the FCFE3083ASB parts list or searching on Sears PartsDirect.
Check these common locations on a free standing gas range:
- Along the oven door frame or interior-side trim, visible when you open the oven door
- On the left-side or right-side front frame area behind the oven door
- On the lower drawer frame (storage or broiler drawer area), visible when the drawer is pulled out
- On the back panel of the range (you may need a flashlight)
Once you have the model number (FCFE3083ASB) and the serial number:
- Use the model number to pull up the correct parts breakdown for your exact range
- Find the part by location (for example: control panel, oven door, wiring, burner box)
- Confirm the part description matches what you are replacing (shape, mounting points, connectors)
- Order by the part number shown for that diagram item
These are examples of parts listed for FCFE3083ASB on our parts list:
| What you are replacing | Example part on this model | What it helps with |
|---|---|---|
| Oven temperature sensing | Probe 5304533448 | Helps the control regulate oven temperature |
| Power connection point | Universal/multiflex (Frigidaire) range terminal block 5303935271 | Helps restore a safe, solid power connection |
| Oven door locking | Latch assemb 5304528257 | Helps the door lock during self-clean (if equipped) |
Using the model and serial tag prevents ordering a look-alike part that does not fit your FCFE3083ASB. That is especially important for electrical items like a terminal block, wiring harnesses, and controls.
Last updated: February 2026
What are the most common stove parts to replace?
For a Frigidaire FCFE3083ASB free standing gas range, the most commonly replaced parts are the ignition and heating-related components (burner and oven), plus high-wear items like door hardware and wiring connections. Replacements usually happen after no-heat, weak heat, ignition clicking, or physical damage.
- Ignition and burner system parts: burner components and related assemblies when a burner won’t light or lights unevenly.
- Oven temperature sensing: a failed temperature sensor can cause overbaking or underbaking; see the probe 5304533448.
- Control and power connection parts: if you see heat damage at the cord connection or intermittent power, check the universal/multiflex (Frigidaire) range terminal block 5303935271.
- Door and drawer parts: worn hinges, latches, glass, or drawer components when the door won’t close, won’t lock, or glass is damaged; examples include the latch assemb 5304528257 and glass 5304528194.
- Wiring and connectors: harness issues can cause dead components or intermittent operation; one example is the harness 5304529016.
- Confirm the symptom: no heat, uneven heat, won’t ignite, error beeps, or physical damage.
- For burner ignition issues: listen for clicking and look for sparking at the burner.
- For baking problems: compare set temperature vs. actual results; temperature swings often point to a sensor issue.
- For intermittent power: inspect the cord connection area for discoloration or a loose connection.
- For door problems: check alignment and whether the latch moves freely.
| Symptom | Most likely part category | Example part on this model page |
|---|---|---|
| Oven overcooks or undercooks | Temperature sensing | Probe |
| Range loses power or shows heat damage at cord | Power connection | Terminal block |
| Door won’t lock or unlock (self-clean issues) | Door latch hardware | Latch assemb |
| Visible cracked door glass | Door glass | Glass |
Replacing the right part restores safe, consistent cooking performance and helps prevent repeat failures (for example, a loose power connection can overheat wiring, and a bad sensor can cause chronic temperature problems).
To order, use the parts list for model FCFE3083ASB on this page, or search by model number on Sears PartsDirect.
Last updated: February 2026
