Professional chefs and at-home gourmands alike need their cooktops performing at their best to turn out the best meals possible. Keeping those stove tops working properly requires high-quality Kenmore cooktop parts to ensure each burner is heating quickly and evenly. When a burner isn't heating as it should, find the Kenmore gas cooktop parts and Kenmore stove top parts that you need to fix the problem at Sears PartsDirect.
Most common Kenmore gas cooktop parts that need replacing
Burner control valve. The burner control valve controls the gas supply going to the surface burner head.
Burner igniter switch. The burner igniter switch sends current to the igniter electrode when you turn on the burner control valve.
Burner head. The burner head evenly distributes gas through slots at the top of the burner head to create a cooking flame.
Spark module. The spark module supplies the igniter electrode with electrical current to create an ignition spark for the burner.
How to replace the spark module on an Electrolux gas cooktop
Unplug the cooktop's power cord from the wall outlet and then close the gas supply shut-off valve.
Remove all the cooktop grates and then lift the gas burner caps off the burner heads. Remove the screws that hold the burner heads in place and then remove the burner heads.
Pull the control knobs off of the burner control valves. Remove the screws that secure the main top to the top of the burner orifice holders. Lift the main top off of the cooktop and set it aside.
Disconnect all the wires attached to the spark module. Release the locking tab and then remove the spark module from the mounting bracket. Discard the spark module.
Position the new spark module on the mounting bracket and push it into place. The locking tab should snap into place when the module is in the right position. Connect the wires to the new spark module.
Position the main top on top of the burner orifice holders. Insert and tighten the screws that secure the main top to the orifice holders. Push the control knobs on the burner control valves.
Position the burner heads in the correct locations, screw them into place and tighten the screws firmly. Cover the burner heads with the burner caps in the correct locations. Set the grates into place on the cooktop.
Plug the power cord into the wall outlet and open the gas shut-off valve.
Sears PartsDirect has the Kenmore cooktop parts you need to keep your range working perfectly
Find the Kenmore cooktop parts you need to keep your gas or electric cooktop working at Sears PartsDirect. We have electric Kenmore stove top replacement parts including Kenmore glass top stove replacement components. If your glass cooktop breaks, get your replacement glass stove top for your Kenmore cooktop from Sears PartsDirect. Use our convenient parts list diagrams to quickly find the Kenmore stove top parts you need to fix any range failure. We have Kenmore glass cooktop replacement parts so you can replace the glass cooktop in your Kenmore stove. When a burner isn't working, we have the Kenmore glass top stove burner replacement parts to fix the problem. Find Kenmore stove accessories on our website as well.
