Kenmore Elite 11173319120 refrigerator Parts

You can find the model and serial number for your Kenmore Elite refrigerator on the identification label inside the fresh food (refrigerator) compartment. For model 11173319120, the label is printed on the interior liner, so you can read it without moving the refrigerator.

Where to look on model 11173319120

Check these common label locations first (use a flashlight and look along the walls and ceiling of the compartment):

• Inside the refrigerator compartment on the interior liner (most common)
• On a side wall near the crisper drawers
• On the ceiling area near the temperature control housing
• Along the door opening frame (hinge side)

What you should write down

We recommend recording both numbers exactly as shown on the label so you can match parts and documentation correctly.

• Model number (example format in the manual: 111.7331* where * is the color code)
• Serial number
• Date of purchase (from your receipt)

Item	What it’s used for	Tip
Model number	Finding the correct parts list and diagrams	Copy every digit; include any suffixes
Serial number	Identifying production details for service	Take a clear photo for reference
Purchase date	Warranty and records	Keep with your manual

Why it matters

The model number ensures you get the right Kenmore Elite refrigerator parts (like shelves, drawers, door bins, or an ice maker component) and the correct procedures for maintenance and troubleshooting in the owner's manual.

Last updated: February 2026

A Kenmore Elite bottom-mount refrigerator like model 11173319120 typically lasts 10 to 15 years. Lifespan depends most on condenser cleanliness, door seal condition, stable temperatures, and avoiding repeated overheating or heavy frost issues; consistent maintenance keeps the sealed system and fans running longer.

Typical lifespan and what usually ends it

Most refrigerators reach end-of-life because of cooling-system wear, airflow problems, or chronic temperature swings.

• 10 to 15 years is the normal service life for modern refrigerators
• Sealed system issues (compressor, refrigerant leak) are the most expensive failures
• Airflow failures (evaporator fan, frost buildup) often show up as warm fridge or warm freezer
• Door gasket leaks shorten life by forcing longer run times
• Water/ice issues (filter restriction, valve problems) are common but usually repairable

Maintenance that adds years (high impact)

We recommend following the care and cleaning guidance in the 11173319120 owner's manual and focusing on these habits.

• Vacuum dust from the condenser area regularly (more often with pets)
• Keep door gaskets clean and sealing flat; fix gaps quickly
• Maintain steady settings; avoid frequent control changes
• Leave space for air circulation around vents and shelves
• Replace the water filter on schedule if your unit is connected to water

Quick “repair vs. replace” guide

Use this as a practical decision check once your refrigerator is past mid-life.

Refrigerator age	What we typically recommend	Why
0 to 5 years	Repair	Parts and labor usually make sense
6 to 10 years	Repair if cooling is stable	Many fixes are still cost-effective
11 to 15 years	Compare repair cost to replacement	Higher chance of major cooling failures
16+ years	Replace if sealed system fails	Sealed system repairs are rarely economical

Why it matters

A refrigerator that runs longer than it should (dirty condenser, leaking gasket, blocked airflow) uses more energy and stresses the compressor. That extra heat and run time is what most often shortens lifespan.

Last updated: February 2026

Common problems we see with the Kenmore Elite refrigerator model 11173319120 are no-cool or warm temperatures (often from Demo mode being on, heavy door opening, or a clogged condenser cover/vents), frost or moisture issues from airflow and door-seal problems, icemaker slow production from low water flow or doors not sealing, and doors that will not close or pop open due to leveling or bin alignment. For model-specific checks and settings, use the 11173319120 owner's manual.

Most common symptoms and what usually causes them

• Refrigerator and freezer not cooling: power cord unplugged, Demo mode enabled, or unit in a defrost cycle
• Too warm in either section: frequent door openings, hot installation location (above 110°F), or warm food load
• Food freezing in fresh food section: items placed near an air vent, temperature set too cold, or room too cold (below 55°F recommended)
• Icemaker not making enough ice: kinked water line, low water pressure (including reverse osmosis systems), or doors not fully closed
• Doors not closing or popping open: shelves/bins out of position, food packages blocking, or refrigerator not leveled

Quick checks we recommend first (in order)

1. Confirm the refrigerator is plugged into a properly grounded 3-prong outlet.
2. Make sure Demo mode is off (lights work in Demo mode, but cooling is disabled).
3. Allow up to 24 hours after installation or moving for temperatures to stabilize.
4. Clean the condenser cover and vents with a vacuum attachment (do not remove the condenser panel).
5. Check door closing: clear obstructions, fully seat bins and drawers, and level the cabinet.

Symptom-to-fix guide

Symptom	What to check	What to do
Not cooling	Demo mode, defrost cycle	Disable Demo mode; wait 30 minutes after defrost cycle
Too warm	Door openings, room heat	Reduce door-open time; avoid operation above 110°F
Food freezing	Air vent placement, control setting	Move high-water foods away from vents; adjust temp 1 step at a time
Low ice production	Kinked line, low pressure	Straighten tubing; address low pressure or RO-related restrictions
Doors pop open	Leveling, bin alignment	Level refrigerator; reposition shelves, bins, and baskets

Why it matters

Cooling, airflow, and door sealing work together. A small issue like Demo mode, a clogged condenser vent, or a door that is not sealing can cause temperature swings, frost, and icemaker complaints that look like bigger failures.

For additional troubleshooting by display code, use Kenmore 111 model bottom freezer refrigerator error codes.

Last updated: February 2026

To raise your Kenmore Elite refrigerator model 11173319120 off the floor, we raise the front corners by turning the leveling legs with the provided wrench. Turn the leveling leg counterclockwise to raise and clockwise to lower, adjusting a little at a time for stability.

Raise the cabinet height (leveling legs)

Follow the model-specific steps and diagrams in the 11173319120 owner's manual. The manual procedure accesses the leveling legs from the freezer compartment.

• Pull open the freezer compartment
• Remove the upper drawer and lower drawer basket to reach the leveling area
• Use the wrench provided with the refrigerator
• Turn the leveling legs:
  • Counterclockwise: raises the front corner
  • Clockwise: lowers the front corner
• Reinstall the basket and drawer, then open and close the freezer several times to confirm smooth operation

Quick checks so the refrigerator stays stable

• Raise both front corners evenly (small turns on each side)
• Stop when the cabinet no longer rocks on the floor
• Keep the front slightly higher if you want better door self-closing
• Confirm the toe grille or kick plate is not rubbing after the adjustment

If “raise” really means the doors or drawer look uneven

The manual also covers height alignment adjustments.

What looks off	What you adjust	Direction to raise
Refrigerator door height	Middle hinge screw nut	Turn counterclockwise
Freezer drawer height (one side low)	Rail bracket position knob and stopper	Adjusts up to about 1/8 inch

Why it matters

Proper leveling improves door sealing, reduces drawer binding, and helps the refrigerator cool efficiently while keeping the front appearance even on slightly uneven floors.

Last updated: February 2026
