Kenmore 25328062801 freezer Parts

An upright freezer like Kenmore model 25328062801 usually stops working because it is not getting power, the temperature control is set to OFF, airflow around the cabinet is blocked, or a cooling-system component (fan, defrost system, or control) has failed. Use the checks in the 25328062801 owner's manual to narrow it down safely.

Quick checks first (most common)

• Confirm the outlet has power (try a lamp); reset the breaker if tripped.
• Make sure the temperature control is not set to OFF.
• Verify the freezer is plugged in fully and the cord is not damaged.
• Check that the door closes and seals; a misaligned door can cause cooling and moisture problems.
• Make sure there is enough clearance for air circulation around the freezer, especially in hot rooms.
• Listen for the evaporator fan inside; no fan noise can point to a fan motor issue.

What to look for based on symptoms

What you notice	Likely cause	What to do next
No lights, no sound	Power supply issue	Check outlet, breaker, cord, and control setting
Runs but not cold	Airflow restriction or sealed-system issue	Improve clearance, check for heavy frost, then evaluate cooling components
Heavy frost buildup, weak cooling	Defrost system problem	Defrost and inspect defrost heater and defrost thermostat
Door hard to shut, frost near door	Door not sealing	Inspect gasket and door alignment

Parts that commonly cause “stopped cooling”

If your basic power checks pass, these model-compatible parts are common suspects:

• Motor 297309000 (evaporator fan motor): freezer may run but not circulate cold air.
• Freezer defrost heater 216730700: frost can choke airflow and stop cooling.
• Chest freezer defrost thermostat 297216600: can prevent proper defrost cycling.
• Freezer electronic control board 297370602: can interrupt compressor/fan operation.
• Freezer door gasket 5304507199: warm air leaks cause frost and poor cooling.

Why it matters

When the freezer is off or not cooling, food safety becomes the priority. The manual notes frozen foods typically stay frozen at least 24 hours during a power failure if the door stays closed, so keeping the door shut buys time while you troubleshoot.

Last updated: January 2026

Yes. On the Kenmore upright freezer model 25328062801, the control panel includes an ALARM RESET button used to silence the “Hi TEMP” alarm and buzzer after a warm-temperature event. This is the practical “reset” most owners need for temperature alarms; it is not a master power reset.

What the ALARM RESET button actually does

When the freezer is first plugged in, or if the inside temperature rises above about 23°F, the “Hi TEMP” indicator can turn on and a buzzer can sound. Pressing ALARM RESET silences the buzzer (the light stays on until the freezer cools back down). See the 25328062801 owner's manual.

• Silences the “Hi TEMP” alarm buzzer
• Helps you acknowledge a power failure or door-left-open event
• Does not repair a cooling problem
• Does not clear all electronic faults on every control style

If you need a true “reset” (power reset)

If the freezer is acting erratically (display issues, not responding, repeated alarms), a safe, common reset is a brief power cycle.

1. Turn the temperature control to OFF (if your control has an OFF position).
2. Unplug the freezer (or switch off the circuit breaker).
3. Wait 5 minutes.
4. Restore power and set the temperature back to your normal setting.

Situation	Best action	What to expect
“Hi TEMP” light on, buzzer sounding	Press ALARM RESET	Buzzer stops; light stays on until temp drops
After outage, freezer warming	Keep door closed; press ALARM RESET	Unit cools back down over time
Display shows an “E”	Arrange service	Indicates a malfunction needing repair

Why it matters

Using the correct reset prevents unnecessary part replacement and helps protect food. If the alarm keeps returning, focus on airflow, door sealing, and defrost performance.

• Confirm the door closes tightly and the gasket seals evenly
• Avoid overpacking; keep vents clear for air circulation
• If frost buildup is heavy, defrost the unit as described in the manual
• If the door switch is intermittent, check the crosley freezer door switch 297243800

Last updated: January 2026

The storage capacity (cubic feet) for Kenmore upright freezer model 25328062801 is listed on the model and serial number plate and in the specifications section of the 25328062801 owner's manual. Use those two sources to get the exact cubic-foot rating for your unit.

Where to find the exact cubic feet

Check these locations in order; they are the fastest ways to confirm capacity for model 25328062801:

• Model and serial number plate: on the upper left wall inside the freezer (upright models)
• Specifications/features section in the 25328062801 owner's manual
• Any product data label that lists “capacity” or “cu. ft.”
• If you still have it, the original sales receipt or product literature for model 25328062801

A practical rule from the manual (helps even before you find the number)

The Use and Care Guide includes a loading guideline you can use immediately for safe freezing.

Task	Manual guideline	What to do
Freezing fresh (unfrozen) food	Freeze 3 lb per cubic foot at one time	Freeze in smaller batches if you are adding a lot at once
First-time startup	Allow 4 hours to cool down	Wait before loading unfrozen food

Why it matters

Cubic feet tells you how much food the freezer is designed to hold and helps prevent overloading. Overloading reduces airflow, can increase frost buildup, and can make the compressor run longer than necessary.

Last updated: January 2026
