Samsung RF27T5501SR/AA-53 refrigerator Parts

To determine your Samsung refrigerator model, we look for the model tag and use the full model code (including the version or revision suffix, such as “/AA-53”) rather than a marketing name. On RF27T5501SR units, the model and serial information is printed on the rating label near a barcode.

Where to find the model tag

Most Samsung bottom-mount and French door refrigerators place the rating label in one of these spots:

• Inside the fresh food compartment on a side wall (often right side)
• On the ceiling area inside the fresh food compartment
• Behind a crisper drawer or near the crisper frame
• On the cabinet wall visible when you open the doors wide

For diagrams and label references specific to your refrigerator family, use the RF27T5501SR owner's manual.

What to write down (so parts match)

When you record the model information, capture these items exactly as shown:

• Model code (example: RF27T5501SR)
• Version or revision (example format: /AA-53)
• Serial number (usually printed next to the barcode)
• Any additional code on the label (sometimes called a BOM name)

Quick example

Label item	What it does	Why it matters
Model code (RF27T5501SR)	Identifies the base platform	Gets you to the correct parts list
Version/revision (/AA-53)	Identifies the exact build	Prevents ordering the wrong door, board, or ice parts
Serial number	Identifies your specific unit	Helps confirm production details when troubleshooting

Why it matters for repairs and parts

Samsung often changes components between revisions. Using the full model code plus the revision helps us match the correct control board, temperature sensor, door gasket, or ice maker related assemblies for your exact build.

Ordering tip

Once you have the full model code and revision, order replacement parts from the parts list for your refrigerator, or search by model on Sears PartsDirect.

Last updated: February 2026

On Samsung model RF27T5501SR, RD is the forced defrost mode for the refrigerator (fresh food) compartment, while FD is the general forced defrost mode used to run a defrost cycle on demand. Use these modes for troubleshooting frost, airflow, and cooling issues; follow the button sequence in the RF27T5501SR owner's manual.

What each mode does

• RD (refrigerator defrost): Targets the fresh food evaporator area; helpful when the refrigerator section is warm but the freezer is closer to normal.
• FD (forced defrost): Runs a forced defrost cycle (commonly used as the main service defrost); helpful when you suspect heavy frost is blocking airflow.
• Both modes are service diagnostics; they are not everyday user settings.

When to use RD vs FD

Use the mode that matches the symptom you are chasing:

• Refrigerator section warming up, weak airflow at fridge vents: try RD
• Frost buildup, fan noise changes, or airflow blocked by ice: try FD
• Ice maker or dispenser issues caused by freezing in the ice room: address defrost and airflow first
• Repeated icing after defrost: inspect door sealing and temperature sensing

Quick symptom-to-check table

Symptom	Most likely area	Mode to try first	Common next check
Fridge warm, freezer OK	Fresh food evaporator	RD	Temperature sensing and airflow
Heavy frost, airflow blocked	Evaporator/air ducts	FD	Evaporator fan operation
Intermittent cooling swings	Controls/sensors	RD then FD	Sensor readings, control response

Why it matters

Choosing the right forced defrost mode saves time. If you run RD when the problem is system-wide frost, you can miss the real restriction; if you run FD when only the refrigerator evaporator is iced up, you can overlook a compartment-specific airflow issue.

Parts that commonly relate to defrost and airflow problems

If forced defrost helps temporarily but the issue returns, these model-compatible parts are often involved:

• Refrigerator temperature sensor DA32-10104V (temperature feedback that affects defrost and cooling)
• Refrigerator evaporator fan motor DA31-00287B (moves air across the evaporator and into compartments)
• Refrigerator door gasket DA97-13015J (poor sealing can drive moisture and frost buildup)

You can order replacement parts for your RF27T5501SR from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

The most common problems we see with Samsung refrigerators like model RF27T5501SR are cooling issues (warm fridge or freezer), ice maker problems (no ice, clumping, jams), and water system troubles (slow dispense or leaks). Basic maintenance and a few quick checks prevent many repeat failures.

Most common issues and what to check first

• Not cooling or weak cooling: confirm vents are not blocked by food packages; the manual warns blocked vents can cause overcooling and water filter damage.
• Ice maker not working or ice clumps: check for a jam in the ice bucket and avoid putting fingers or objects in the ice chute.
• Water leaks or slow water dispense: replace the water filter on schedule and make sure the filter seats fully.
• Noisy operation: fan noise often points to frost buildup or a failing fan motor.
• Intermittent power or dead display: a control board or power issue can cause resets or no response.

Quick troubleshooting steps (safe, high-impact)

1. Make sure doors close tightly and nothing is preventing a full seal.
2. Keep interior air vents clear; do not pack items against the back wall.
3. If you unplug the refrigerator, wait at least 5 minutes before plugging it back in.
4. If you smell burning or see smoke, unplug the refrigerator immediately.
5. Do not attempt to repair or modify internal components yourself; use the safety guidance in the RF27T5501SR owner's manual.

Parts that commonly relate to these symptoms

Symptom	Likely system	Example part on this model page
Warm fridge/freezer, fan noise	Airflow/evaporator area	Refrigerator evaporator fan motor DA31-00287B
Slow water, leaks near filter area	Water filter housing	Samsung refrigerator water filter housing assembly DA97-21041A
Ice dispensing issues, grinding	Ice bucket/auger drive	Refrigerator auger motor assembly DA97-12540G

Why it matters

Cooling and ice maker complaints often share the same root causes: restricted airflow, door sealing problems, or water system restrictions. Fixing the underlying cause protects food safety, reduces frost buildup, and helps the compressor run less.

For replacement parts for RF27T5501SR, use the parts list for this model or search by model number on Sears PartsDirect.

Last updated: February 2026

Most Samsung refrigerators, including the Samsung RF27T5501SR, last 10 to 15 years with normal household use. You can often reach the high end of that range by keeping airflow clear, maintaining door seals, and staying on top of water and ice system maintenance listed in the RF27T5501SR owner's manual.

Typical lifespan and what affects it

A refrigerator’s life is mainly driven by compressor run time, airflow, and how well the doors seal.

• 10 to 15 years is the typical lifespan for modern refrigerators
• Heavy use (frequent door openings, warm garage installs) shortens lifespan
• Poor airflow (blocked vents, dusty condenser area) increases run time and wear
• Water leaks or ice buildup can lead to fan, sensor, or control issues
• Timely replacement of worn parts (gaskets, sensors, fans) extends service life

Quick maintenance checklist (best ROI)

These steps reduce strain on the sealed system and help temperatures stay stable.

• Keep interior air vents unblocked so cold air can circulate
• Confirm doors close fully; avoid overloading door bins
• Clean spills promptly to prevent odors and drain issues
• Keep ice maker and dispenser area free of clumps and frost
• Replace failed cooling components quickly if you notice warming or loud fan noise

Common “life-extending” repairs for this model

If cooling is inconsistent, ice production drops, or you hear abnormal fan noise, these parts are commonly involved on French door and bottom-mount designs.

Symptom	Common cause	Example part on this model page
Warm fridge or freezer, noisy airflow	Evaporator fan not running or restricted	Refrigerator evaporator fan motor DA31-00287B
Temps swing, food freezing or warming	Sensor reading wrong temperature	Refrigerator temperature sensor DA32-10104V
Frost buildup, weak airflow in freezer	Evaporator cover/fan issue	Samsung refrigerator freezer evaporator cover and fan assembly DA97-21002A

Why it matters

A refrigerator that runs longer to hold temperature wears out the compressor and fans faster. Simple airflow and sealing checks reduce run time, stabilize temperatures, and help you get the full expected lifespan.

For parts and diagrams specific to RF27T5501SR, use the parts list on this model page; for broader model lookups and ordering, use Sears PartsDirect.

Last updated: February 2026
