KitchenAid KSM60SECXER0 stand mixer Parts

The “best” KitchenAid stand mixer depends on what you make most often: for frequent bread dough and large batches, a bowl-lift model in the 6 to 7 quart range is the top choice; for everyday cookies and cakes, a tilt-head model is usually the best fit. For parts and repairs, this page is for KitchenAid model KSM60SECXER0.

How to choose the best KitchenAid stand mixer for you

We recommend matching the mixer style to your typical workload and kitchen setup.

• Bowl-lift: best for heavy doughs, big batches, and frequent use
• Tilt-head: best for everyday mixing and easier bowl access
• Bowl size: 5 to 7 quarts covers most home baking needs
• Motor and control: consistent speed under load matters more than peak watt claims
• Attachments: confirm bowl and beater compatibility before buying extras

Quick comparison

Feature	Bowl-lift (6 to 7 quart)	Tilt-head (4.5 to 5 quart)
Best for	Bread dough, double batches	Cookies, cakes, quick mixes
Stability	Very stable under load	Stable for lighter to medium loads
Access	Bowl raises/lowers	Head tilts up
Typical footprint	Larger/heavier	Smaller/lighter

Why it matters (especially for repairs and parts)

Choosing the right style helps prevent common issues like slow mixing under load, overheating, and premature gear wear. If your current mixer is KSM60SECXER0, keeping it running smoothly often comes down to maintaining the drive system and speed control.

Parts that commonly relate to performance issues on KSM60SECXER0

If your mixer has speed problems (surging, only one speed, or inconsistent power), these model-specific parts are often involved:

• Control assembly, 120 volt W11677161 (speed control and power regulation)
• Gear, ring and plate assembly W11647948 (drive components that transfer motor power)

For symptom-based troubleshooting steps, use our DIY guide: stand mixer runs on high-speed only.

Last updated: February 2026

For the KitchenAid KSM60SECXER0 stand mixer, the most common issues we see are beater-to-bowl clearance problems (beater rubs or misses ingredients), grease or oil seepage from aging gearcase lubricant, and speed or shutoff problems caused by worn drive components or an electrical control issue such as the control assembly, 120 volt W11677161.

Most common problems (and what they look like)

• Attachments rub the bowl: scraping sound, metal marks, or the beater stalls in thick dough.
• Attachments sit too high: ingredients collect at the bottom and do not mix evenly.
• Oil or grease leak: oily drips or streaks near the planetary area after storage or heavy use.
• Runs only on one speed or speeds drift: jumps to fast, will not hold a steady speed.
• Stops mid-mix: may restart after cooling; often happens with heavy loads.

Quick checks we recommend first

1. Unplug the mixer and remove the bowl and attachment.
2. Check beater clearance (a simple clearance check with the flat beater installed).
3. Reduce load: very stiff doughs can trigger overheating or strain gears.
4. Listen for gear noise: loud grinding or clicking points to internal gear wear.
5. Watch the speed control: if the motor surges or only runs high, focus on the speed control system.

Common symptoms and the likely fix

Symptom	Most likely cause	Typical fix
Beater hits bowl	Beater height out of adjustment	Adjust beater clearance; recheck after tightening
Oil/grease seepage	Gearcase lubricant separating with age	Clean exterior; service and re-grease gearcase
Only high speed	Control components out of range	Diagnose and replace control parts as needed
Slow rotation under load	Worn gears or drag in gearcase	Inspect gears; replace worn gear components

Helpful DIY guidance

• For bowl contact issues, use our guide: stand mixer attachments rub the bottom of the bowl.
• For speed-control problems, use: stand mixer runs on high-speed only.
• For oil seepage, use: stand mixer leaks oil.

Why it matters

Running a mixer with incorrect beater clearance or a failing gearcase can damage the bowl, strip gears, and overload the motor. Catching the symptom early usually keeps the repair limited to adjustment, lubrication service, or a targeted part replacement.

Last updated: February 2026

Yes. For your KitchenAid stand mixer model KSM60SECXER0, we sell replacement parts so you can repair common issues like speed control problems, worn gears, or damaged bowls and attachments. Use your model number to match parts exactly and avoid fit or color mismatches.

The simplest way to get the right part

We recommend matching by model number first, then confirming the part by name and ID.

• Find your model tag and confirm it reads KSM60SECXER0
• Choose the part category that matches the symptom (controls, gearcase, bowl, base)
• Match the part ID and description before ordering
• If your mixer has a specific finish, match color-specific parts (for example, empire red vs contour silver)
• Replace mounting hardware if it is stripped or missing

Common replacement parts for KSM60SECXER0

These are examples of parts available for this model that customers often replace:

• Speed or power issues: control assembly, 120 volt W11677161
• Bowl damage or missing bowl: bowl, 6 quart (brushed) W11762674
• Gear noise or poor mixing action: gear, ring and plate assembly W11647948
• Attachment performance upgrades: beater, flex edge W10778038

Quick fit check before you order

What you are replacing	What to verify	Why it helps
Control components	Mixer runs, surges, or only runs at one speed	Prevents ordering the wrong electrical part
Gearcase or gears	Grinding, clicking, slow rotation under load	Targets the drive system, not the bowl/attachment
Bowl or beater	Fit, capacity (6 quart), and finish	Avoids clearance issues and cosmetic mismatch

Why it matters

Stand mixers are model-specific inside the gearcase and speed control area. Using the exact KSM60SECXER0 parts list helps ensure proper fit, safe operation, and consistent mixing performance.

Last updated: February 2026

Yes. The KitchenAid KSM60SECXER0 is a strong choice when you want a durable stand mixer for frequent baking and heavier mixing tasks (cookie dough, bread dough, large batters). It is built to handle bigger batches, but it can be louder and heavier than smaller tilt-head mixers.

What “good” means for this model

A stand mixer is a good fit when it matches your typical batch size and workload. For the KSM60SECXER0, we look at power delivery, stability, and serviceability.

Strengths you’ll notice

• Handles thicker doughs and larger batches without constant stopping and scraping
• Bowl-lift style stability helps keep the mixer planted during heavy mixing
• Many wear items are replaceable if performance drops over time
• Common repairs are straightforward when you can identify the failing system (speed control, gears, brushes)

Tradeoffs to expect

• More noise and vibration than lightweight mixers, especially under load
• Heavier footprint on the counter and more steps to raise/lower the bowl
• If the beater-to-bowl clearance is off, attachments can rub until adjusted

Quick “fit check” (use this to decide)

If you mostly make...	KSM60SECXER0 fit	Why
Bread dough, bagels, pizza dough	Excellent	Better stability and torque under load
Big cookie batches, thick batters	Excellent	Less bogging down at lower speeds
Small frosting batches, light whipping	Good	Works well, but size/noise may feel like overkill

When performance problems are fixable (and what to check)

If your mixer runs only on one speed, surges, or will not run, the speed control system is a common place to start. On this model, the control assembly, 120 volt W11677161 is the key part that manages speed and operation.

For symptom-based troubleshooting, we use these guides:

• Stand mixer runs on high-speed only
• Stand mixer won't run at all
• Stand mixer attachments rub the bottom of the bowl

Why it matters

Choosing the right stand mixer is about matching capacity and torque to your recipes. A mixer that is “too small” strains gears and control components; a mixer that is “too big” can be inconvenient day-to-day. The KSM60SECXER0 is best when you regularly mix heavier loads and want a repairable, long-term machine.

Last updated: February 2026

The wattage for your KitchenAid KSM60SECXER0 stand mixer is listed on the unit’s rating label (not on the parts list). Check the label on the base or rear housing; it will show watts (W) or amps (A) for your exact mixer.

How to find the wattage on the mixer

• Unplug the mixer before checking the label.
• Look on the underside of the base first.
• If it’s not there, check the rear housing near the cord entry.
• Find the line that lists W (watts) or A (amps).
• Write down the value exactly as shown for future parts and electrical checks.

If the label shows amps instead of watts

You can convert amps to watts using your household voltage (most U.S. kitchens are 120V).

Label shows	Use this formula	Example at 120V
Amps (A)	Watts = Volts × Amps	3.0A = 360W
Watts (W)	No conversion needed	350W listed

Why it matters

Wattage is an electrical rating; it helps you compare power draw and confirm you’re using the correct outlet and circuit. Mixing strength also depends on the gearcase and speed control, not just the watt number.

When performance issues point to a part problem

If your KSM60SECXER0 struggles, surges, or runs at the wrong speed, focus on the speed control and drive system:

• Runs on high speed only or won’t change speeds
• Slows down under normal loads
• Starts and stops when you move the speed lever
• Has intermittent power while the cord is steady

For speed-control symptoms, a common starting point is the control assembly, 120 volt W11677161. For step-by-step troubleshooting, use our guide: stand mixer runs on high-speed only.

Last updated: February 2026
