Kenmore Elite 11172795020 refrigerator Parts

A Kenmore Elite refrigerator typically lasts 12 to 15 years. For your Kenmore Elite 11172795020 bottom-mount refrigerator, steady temperatures, clean condenser airflow, and correct door sealing are the biggest factors that keep it running reliably over that full lifespan range.

Typical lifespan at a glance

Item	Typical range	What shortens it fastest
Kenmore Elite refrigerator lifespan	12 to 15 years	Poor ventilation, dirty condenser area, warm door gaskets
Sealed refrigerant system coverage (from the manual)	5 years	Overheating from blocked airflow, heavy dust buildup
Full appliance coverage (from the manual)	1 year	Installation or maintenance issues

What we do to help it reach 12 to 15 years

• Keep vents and airflow paths clear so the compressor can shed heat.
• Clean dust from the condenser area regularly (especially with pets).
• Confirm doors close fully and gaskets seal all the way around.
• Keep the refrigerator and freezer set to stable, food-safe temperatures.
• Replace the water filter on schedule if your model uses one.

Quick maintenance checklist (monthly to quarterly)

• Listen for fan noise changes: a failing evaporator fan can reduce cooling and increase run time.
• Check for frost or warm spots: early signs of airflow or defrost issues.
• Inspect door alignment: sagging doors can cause air leaks and moisture buildup.
• Look for water under the unit: often tied to drain or ice maker water supply issues.

Why it matters

Most “early failures” are really heat and airflow problems. When the condenser area is dusty or ventilation is tight, the compressor runs hotter and longer, which accelerates wear on the sealed system and cooling components.

Helpful model-specific resources

• Warranty terms, care and cleaning, and troubleshooting steps are in the 11172795020 owner's manual.
• If you see a code on the display, use our Kenmore 111 model bottom freezer refrigerator error codes guide to narrow down the cause.

Last updated: February 2026

To raise your Kenmore Elite refrigerator model 11172795020 off the floor, we adjust the front leveling legs to lift the front corners. This model is designed to be raised and leveled using the included wrench so the cabinet sits stable and the doors align correctly (not by lifting the whole unit with shims).

How to raise and level the front (recommended)

1. Open the freezer compartment and remove the upper drawer and lower drawer basket to access the leveling legs.
2. Use the wrench that came with the refrigerator.
3. Turn each front leveling leg:
   • Counterclockwise to raise the front corner.
   • Clockwise to lower the front corner.
4. Reinstall the baskets/drawers and open and close the freezer several times to confirm smooth operation.

Quick checklist

• Raise both front corners evenly, then fine-tune side-to-side.
• Keep the refrigerator stable; it should not rock.
• Recheck door alignment after leveling.

Safety and floor-protection tips

Your refrigerator is heavy, so we focus on controlled adjustments and protecting flooring.

• Unload heavy items from doors and lower shelves before adjusting.
• Pull the refrigerator straight out if you must move it; do not “walk” it.
• Protect the floor with a rigid floor protector or heavy cardboard while repositioning.
• Avoid lifting the cabinet by the doors or handles.
• If the unit must be raised more than the leveling legs allow, correct the floor issue rather than forcing extra lift.

When the doors still look uneven

This model also allows door-height correction after leveling.

Symptom	Most likely fix	Where to adjust
Refrigerator doors look uneven	Door height adjustment	Middle hinge screw nut
Freezer drawer sits low on one side	Drawer rail height adjustment	Rail bracket/stopper position

For the exact adjustment points and steps, use the owner's manual.

Why it matters

Proper leveling helps the doors seal consistently, improves temperature stability, and prevents drawer binding. It also reduces vibration and protects the floor from damage caused by shifting.

Last updated: February 2026

Common problems we see with the Kenmore Elite bottom-mount refrigerator model 11172795020 include cooling issues (often tied to airflow), ice maker not making ice, water supply or filter restrictions, and control or sensor-related faults. Our 11172795020 owner's manual troubleshooting section helps you match symptoms to the right checks.

Most common symptoms and what they usually point to

• Not cooling or warm temperatures: airflow blockage, evaporator fan issue, dirty condenser area, or a defrost problem
• Ice maker not working: ice maker turned OFF, water supply shutoff closed, frozen fill tube, or low water pressure
• Water dispenser slow or no water: clogged water filter, kinked water line, or inlet valve issue
• Bad odors in fresh food section: spoiled food, spills, or an air filter that needs replacement
• Noises (banging, clicking, fan noise): normal ice drop sounds, fan contacting ice buildup, or vibration from leveling

Quick checks we recommend first (before replacing parts)

1. Confirm temperature settings: 37°F for refrigerator and 0°F for freezer are typical targets.
2. Make sure vents inside the compartments are not blocked by food packages.
3. If ice is the issue, verify the ice maker is set to ON and the water supply valve is open.
4. Replace the water filter on schedule; restrictions commonly cause weak water flow and ice maker fill problems.
5. Check door seals for gaps and confirm the doors close fully.

Symptom-to-likely-cause guide

Symptom	Most likely cause	Best first action
Freezer cold, fridge warm	Airflow/evaporator fan or frost buildup	Inspect vents; listen for fan; check for heavy frost
No ice production	Ice maker OFF or no water supply	Turn ice maker ON; confirm water valve open
Slow water flow	Filter restriction	Replace filter; flush several cups of water
Odor in refrigerator	Food spills or air filter	Clean spills; replace air filter if equipped

Why it matters

Catching airflow, filter, and door-seal problems early prevents temperature swings that can spoil food, reduce ice production, and make the compressor run longer than necessary.

For model-specific operating details like turning the ice maker ON/OFF and the troubleshooting chart, use the 11172795020 owner's manual. For step-by-step filter guidance, see how to replace the water filter in a Kenmore refrigerator.

Last updated: February 2026

Your Kenmore Elite refrigerator’s model number is printed on the appliance’s rating label (model and serial tag). On Kenmore Elite model 11172795020, the label is typically inside the fresh food compartment on a side wall or ceiling area; confirm the exact label location and format in the owner's manual.

Where to look for the model number label

Check these common spots first (use a flashlight and look for a white or silver sticker/plate):

• Inside the refrigerator compartment on the left or right side wall
• On the ceiling of the fresh food compartment near the lights
• Behind or beside the crisper drawers (on the wall behind the drawers)
• Along the door frame (visible when the door is open)
• Inside the freezer compartment on a side wall (less common on bottom-mount units)

What the model number looks like

For this Kenmore Elite bottom-freezer platform, the model family is shown as 111.7279* in the Use & Care Guide; your full model number includes the complete digits and may include a color suffix.

What you see	What it means	Example
Model family	Shared platform for multiple finishes	111.7279*
Full model number	Exact version used for parts and service	11172795020
Serial number	Unique ID for your specific unit	Varies

Why it matters

We use the exact model number to match the correct refrigerator parts, door bins, drawers, water filter style, and electronic control components. Even small model variations can change fit and wiring.

Tips to avoid mix-ups

• Write the model number exactly as shown (include all digits)
• Take a clear photo of the label before ordering parts
• If the label is hard to read, gently clean it with a damp cloth and dry it
• Use the model number (not the marketing name “Kenmore Elite”) when searching

Last updated: February 2026

On Kenmore Elite refrigerator model 11172795020, a “bad compressor” usually shows up as poor or no cooling while the unit tries to run. Before condemning the compressor, we rule out common look-alikes such as Demo Mode, dirty condenser airflow, or a normal long run time in warm conditions (the manual notes about 40% to 80% run time at 70°F).

Quick checks before blaming the compressor

• Confirm the refrigerator is not in Demo Mode (cooling is disabled in Demo Mode).
• Verify the power cord is fully plugged into a grounded 3-prong outlet.
• Give a new install time; the manual notes it can take up to 24 hours to reach set temperatures.
• Check door closure; frequent openings and doors not sealing raise temps and increase run time.
• Clean airflow at the condenser cover and vents with a vacuum; do not remove the condenser panel/cover.

Signs that point more strongly to a compressor problem

These symptoms are more suspicious when the items above check out:

What you notice	What it often means	What to do next
Repeated clicking every few minutes and no cooling	Start device/overload issue or compressor not starting	Have the start components and compressor electrically tested
Compressor runs hot and fridge stays warm	Compressor running inefficiently or sealed system issue	Check condenser airflow first; then schedule sealed-system diagnosis
Compressor is quiet (not running) but fans/lights work	Control/start circuit issue or compressor not starting	Verify not in Demo Mode; then test start circuit and compressor

Why it matters

A compressor diagnosis affects both cost and repair approach. Many “compressor” complaints are actually settings (Demo Mode), airflow restrictions, or door seal/usage issues that you can correct quickly without sealed-system work.

Where to confirm model-specific troubleshooting steps

Use the Troubleshooting Guide and control settings details in the owner's manual for model 11172795020.

Last updated: February 2026
