Official Electrolux wall oven/microwave combo parts

Common replacement parts for Electrolux wall oven microwave combos

• Thermal switch. The thermal switch is located on the back of the wall oven. It trips if the wall oven overheats.
• Electronic oven control board. The electronic oven control board senses oven temperature and cycles the bake element and broil element on and off to maintain the oven temperature that you set on the control panel.
• Control panel. The control panel houses the selection buttons that allow you to choose oven settings and the control display.
• Oven temperature sensor. The oven temperature sensor detects oven temperature and sends the temperature signal to the electronic control board to help maintain set oven temperature.

Replacing oven door hinges in your Electrolux wall oven microwave combo

• Fully open the oven door. Use a slot screwdriver to pry down the locking tabs to the unlocked position on both sides of the door. Raise the door to the broil stop position, which is about 1/4 open. Grip both sides of the oven door and then lift up and out to remove the door.
• Carefully place the oven door face down on a padded surface, such as a towel-covered table. Using the type of screwdriver that fits the screws, remove the screws that secure the door handle to the top of the oven door. Remove the handle.
• Remove the screws at the bottom of the oven door. Lift the inner door panel assembly off the outer door panel and set it on the padded surface.
• Remove the 2 screws on the inner oven door panel that secure each door hinge in place. Pull the hinges up and out of the inner door panel.
• Position the new door hinges in place in the inner door panel assembly. Insert the screws in the new door hinges and tighten the screws firmly.
• Reassemble the door and reinstall the door on the oven.
