Samsung ME17R7021EG/AA-01 microwave/hood combo Parts

To replace the charcoal filter on your Samsung ME17R7021EG microwave/hood combo, unplug the microwave (or turn off power at the breaker), remove the vent grille, release the filter hook, slide the old charcoal filter out, then install the new filter at the same angle and reinstall the grille. See the steps in the owner's manual.

Step-by-step: charcoal filter replacement

• Unplug the microwave or switch off power at the main electrical panel.
• Open the microwave door.
• Remove the vent grille mounting screws (the 3 middle screws).
• Slide the vent grille to the left, then pull it straight out.
• Push the hook to release the old charcoal filter, then remove it.
• Slide the new charcoal filter into place; it should rest at an angle.
• Reinstall the vent grille and the 3 screws, close the door, restore power, then set the clock.

Replacement schedule and what to expect

Samsung specifies replacing the charcoal filter (for recirculating, indoor-venting setups) every 6 to 12 months, and more often if needed. The charcoal filter is not washable.

Quick check: charcoal filter vs grease filter

Filter type	What it does	Cleaning/replacement
Charcoal filter	Reduces odors for recirculating venting	Replace every 6 to 12 months (not cleanable)
Grease filter (metal)	Captures grease from cooking vapors	Remove and clean about monthly

Why it matters

A fresh charcoal filter helps your ME17R7021EG vent system control cooking odors and keeps airflow more consistent when venting back into the kitchen.

Ordering the right part

We recommend ordering the charcoal filter by matching your full model number (ME17R7021EG) in the parts list for this model, or searching by model on Sears PartsDirect to ensure the correct fit.

Last updated: February 2026

For a Samsung ME17R7021EG microwave/hood combo, most repairs typically total $150 to $400 (parts plus labor). Smaller fixes (like a door interlock issue) often land lower, while no-heat problems involving high-voltage parts usually cost more; see the safety notes in the ME17R7021EG owner's manual.

Typical repair cost ranges (parts plus labor)

These ranges reflect common microwave/hood combo repairs and what we see most often in the field.

• Minor electrical or door-safety repairs: $150 to $250
• Heating system repairs (no heat): $250 to $500
• Control or display problems: $250 to $450
• Cosmetic or door hardware repairs: $150 to $400
• Vent hood items (filters, lenses): $50 to $200

What drives the price up or down

A microwave/hood combo like the Samsung ME17R7021EG can vary widely in cost depending on what failed and how hard it is to access.

• Which part failed (high-voltage parts cost more than filters or switches)
• Labor time (over-the-range units take longer to remove and reinstall)
• Diagnosis time (intermittent issues can add time)
• Multiple parts (a failed door latch can also damage a switch)
• Age and condition (worn door alignment can repeat failures)

Common parts that affect repair cost

Here are examples of parts on this model that often relate to higher-cost repairs:

Symptom	Common part category	Example part on this model
Runs but does not heat	High-voltage system	Microwave magnetron OM75P-21-ESGN
Blows fuse or trips breaker	High-voltage component	Microwave high-voltage diode DE91-70063D
Dead unit or intermittent power	Power feed	Microwave power cord DE96-00218C
Won’t start, door error	Door safety/interlock	Microwave door interlock switch 3405-001034

Why it matters

Microwaves contain dangerous high voltage components. The ME17R7021EG manual specifically warns against opening the chassis or attempting internal repairs; safe diagnosis and repair decisions help prevent repeat failures and reduce the chance of replacing expensive parts unnecessarily.

How we recommend you proceed

• Start with the symptom: no power, no heat, won’t start, sparking, or fan/light only.
• Use the troubleshooting and safety guidance in the ME17R7021EG owner's manual.
• Price out likely parts for your symptom from the parts list for this model.
• If you’re ordering parts beyond basic filters or lenses, plan for professional service due to high voltage.
• To search parts by model number and compare options, use Sears PartsDirect.

Last updated: February 2026

If the exhaust fan on your Samsung ME17R7021EG microwave/hood combo is not working, the most common causes are a vent setting issue, a power issue, or airflow restriction from a dirty grease filter. Start with the vent mode and basic power checks, then clean the filters.

Quick checks first (no tools)

• Set the vent fan to High; this model’s vent fan only runs at low speed while the microwave is cooking.
• Confirm the microwave has power (display on, clock set); reset the breaker if needed.
• Remove and wash the grease filters; heavy buildup can restrict airflow and make the fan seem ineffective.
• Make sure the vent grille area is not blocked by grease or debris.
• If the fan runs but suction is weak, recheck the vent mode and filter condition.

Filter and airflow maintenance

A clogged grease filter is a frequent reason customers report “fan not working” because airflow drops sharply.

• Wash metal grease filters with hot water and degreasing dish soap; dry fully before reinstalling.
• If your unit is set up for recirculating (non-ducted) venting, replace the charcoal filter on schedule.
• Keep the vent grille clean so air can exit freely.

Symptom	What it usually means	What to do
Fan won’t turn on at all	Control, wiring, or motor circuit issue	Do the power reset steps; then move to service-level diagnosis
Fan runs but weak suction	Low speed mode, dirty filters, blocked airflow	Set vent to High; clean/replace filters
Fan only seems low while cooking	Normal operation for this model	Use High when not cooking if you need more ventilation

Parts that commonly relate to fan complaints

If basic checks do not restore operation, we typically see electrical or control issues that require safe, service-level testing.

• Microwave wire harness DE96-00740D (loose or damaged connections can interrupt the vent circuit)
• Assy pcb main DE92-04327A (control board issues can prevent the vent motor from being powered)
• Microwave thermostat DE47-20059B (an overheat condition can affect operation until the unit cools)

Why it matters

The exhaust fan protects cabinets and electronics by moving heat, steam, and grease away from the cooktop. Keeping filters clean helps ventilation performance and reduces heat buildup during cooking.

For filter cleaning and vent operation details specific to ME17R7021EG, use the owner's manual. For ordering replacement parts by model number, we also support search on Sears PartsDirect.

Last updated: February 2026

The Samsung ME17R7021EG microwave/hood combo is rated at 1000 watts of cooking power output. That is the heating power delivered to the food; the unit’s electrical draw from the outlet (power consumption) is higher.

Cooking watts vs. power consumption (what you are really asking)

Microwaves list two watt numbers; they mean different things:

• Power output (cooking watts): how strongly it heats food (ME17R7021EG: 1000 W)
• Power consumption (input watts): what it draws from your 120 V outlet while running
• Vent fan and lights: add load, but do not increase cooking output
• 10 power levels: change duty cycle, not the maximum output rating

Quick spec snapshot (from the manual)

Spec	What it means	ME17R7021EG value
Power output	Cooking/heating power	1000 W
Power source	Household supply	120 V AC, 60 Hz
Controls	Power settings	10 power levels (incl. defrost)

Why it matters

Knowing the 1000 W output helps you set cook times correctly (especially when converting recipes written for 700 W or 1100 W microwaves). Knowing input watts helps with electrical planning, such as sharing a circuit with other kitchen loads.

Where to confirm the exact rating for your version

We recommend checking the specifications section in the ME17R7021EG owner's manual. That section lists the model family (ME17R7021E*/AA/A2 and ME17R7021E*/AC) and the wattage ratings used for those versions.

Parts that affect heating performance

If your microwave runs but does not heat, common heating-system components include:

• Microwave magnetron OM75P-21-ESGN (creates microwave energy)
• Microwave high-voltage diode DE91-70063D (part of the high-voltage circuit)
• Microwave high-voltage capacitor 2501-001011 (stores high voltage)
• Microwave high-voltage transformer DE26-00122B (steps voltage up)

You can order replacement parts for ME17R7021EG from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026
