Kenmore 79690318900 dryer Parts

For Kenmore dryer model 79690318900, the model number is printed on the identification plate inside the dryer door. Open the door and look on the cabinet frame area around the opening; the same plate typically lists the serial number.

Check these common label locations first:

• Inside the door opening on the cabinet frame (most common)
• Along the inner door frame edge where the door closes
• Just inside the front panel lip near the lint screen opening
• If the label is worn, use a flashlight and look for faint stamped or printed text

The identification plate usually includes multiple fields. Copy them exactly:

• Model number (example format: 796.9031****)
• Serial number
• Electrical rating (useful for parts matching)
• Gas or electric designation (helps confirm the correct version)

Kenmore model numbers can look similar across different dryer series. Using the exact model number from the door label helps us match the correct parts list, troubleshooting steps, and specifications in the 79690318900 owner's manual.

Last updated: February 2026

For the Kenmore dryer model 79690318900, the drying capacity is IEC 7.3 cu. ft., which is considered a full-size dryer. “Kenmore 80 series” can refer to multiple designs, so capacity varies by the exact model number on the rating label.

We match size by the model number, not the “80 series” label. For your dryer, the capacity and key dimensions are listed in the 79690318900 owner's manual.

• Check the model tag inside the dryer door for the full model number
• Use the capacity (cu. ft.) to compare dryers accurately
• Use cabinet dimensions to confirm fit in a laundry closet or alcove
• If you are stacking or using a pedestal, allow for added height and clearance

Kenmore “80 series” is a series name used across different manufacturers and years. Some older 80 series units (often Whirlpool-built 110-prefix models) are commonly around the low 3 cu. ft. range, while many later full-size Kenmore dryers, including 796-prefix models like 79690318900, are much larger.

• Plan for at least 5 1/2 in. behind the dryer for exhaust ducting in many installs
• Allow at least 1 in. on the sides and back to reduce vibration and noise
• Leave at least 21 in. in front for door swing and loading
• If venting is restricted, drying times increase even if the dryer is “full size”

Last updated: February 2026

Yes. For Kenmore dryer model 79690318900, the most reliable “reset” is a power reset: turn the dryer off, unplug it (or switch the breaker off) for about 1 minute, then restore power and start a cycle again. For control-related issues, also check settings like Control Lock in the 79690318900 owner's manual.

• Press Power/Off to stop the dryer.
• Unplug the dryer (or turn the circuit breaker OFF).
• Wait 60 seconds.
• Restore power.
• Press Start/Pause to run a cycle.
• If the dryer was paused or stopped, open and close the door once, then press Start/Pause again.

The manual’s troubleshooting points to power and door-start conditions first.

• Confirm the outlet has power; reset the breaker or replace a blown fuse.
• Make sure the plug is fully seated in the outlet.
• Close the door firmly; a failed door switch can prevent starting.
• If the dryer stopped and sat for more than 4 minutes, it can shut off automatically; press Power and restart.
• If Control Lock is enabled, press and hold the Control Lock button for 5 seconds to unlock.

A “reset” clears minor control glitches, but it will not fix a hard failure like a tripped breaker, a bad door switch, or a wiring problem. Checking power and door-start inputs prevents unnecessary part replacement.

Last updated: February 2026

For a Kenmore dryer like model 79690318900, the typical cost to replace a heating element is about $150 to $400 total (part plus labor). If you DIY, you’ll usually pay about $50 to $200 for the part; a service call and labor often add $100 to $250.

• Electric vs. gas dryer: electric models use a heating element; gas models heat with an igniter, gas valve, and burner components.
• Service call minimums: many repairs include a base trip/diagnostic fee.
• What failed besides the element: restricted venting can overheat and damage thermostats or fuses.
• Access time: some dryers require more disassembly to reach the heater housing.
• Parts quality and availability: OEM parts cost more but fit correctly.

We recommend checking these common “no heat” causes first because they can mimic a bad element:

• Lint screen and vent duct: lint buildup reduces airflow and causes overheating.
• Thermal cut-out/high-limit thermostat: can open if the dryer overheats.
• Power supply (electric models): the dryer needs a dedicated 240 VAC circuit; a partial power loss can let the drum run with no heat.
• Cycle and settings: verify you’re not on an air-fluff/no-heat option.

For model-specific safety and electrical requirements, follow the 79690318900 owner’s manual.

Replacing the heating element without fixing poor airflow or an overheating condition can lead to repeat failures and longer dry times. The manual also recommends checking venting and cleaning ductwork at least yearly to maintain performance.

Last updated: February 2026
